turning diameter over bed 520 mm︱turning diameter over slide rest 310 mm︱turning length 1500 mm︱turning speed range 9-1800 U/min︱main drive motor 11 kW︱tailstock quill taper MT 5 ︱quill adjustment - autom. and manual 200 mm︱weight of the machine ca. 3 t︱dimensions of the machine ca. 3,5x1,3x1,3 m︱

---

turning diameter 500 mm︱turning length 750 mm︱control Fanuc ︱turning dia. over face-slide 280 mm︱travel -x axis 220 mm︱travel -z axis 840 mm︱axial and face feeds 10 m/min︱spindle turning speed range 28-4000 U/min︱total power requirement 23-30 kW︱weight of the machine ca. 8,5 t︱dimensions of the machine ca. 4,2x2,3x2,55 m︱

---

turning diameter 420 mm︱turning length 1000 mm︱control Philips B 2 T ︱Power connection 79 kVA︱turning speed - milling spindle 22,4-3550 U/min︱Working speed 0,1-10.000 m/min︱rapid speed 10 m/min︱Number of tools 12 St.︱spindle bore 78 mm︱drive of main spindle 36 kW︱max. torque on the working spindle 1600 Nm︱total power requirement kW︱weight of the machine ca. 9,7 t︱dimensions of the machine ca. 6,3x2,2x2,2 m︱

---

- tool measuring on board

turning diameter over bed 4000 mm︱turning diameter over slide rest 3500 mm︱turning length 10950 mm︱turning speed range: 1-300 U/min︱power capacity 171 kW︱workpiece weight with 2 steadies 180000 kg︱max. workpiece weight between centres 75000 kg︱Total weight, approx. 350.000 kg︱dimensions of the machine ca. 28,6 x 10,8 x 4,1 m︱workpiece weight with one steady 140000 kg︱max. workpiece weight -without tailstock 10000 kg︱faceplate diameter 2200 mm︱turning speed range - C-axis 0-5 U/min︱max. torque on the working spindle ca. 7200 Nm︱tailstock - quill dia 530 mm︱quill adjustment - autom. and manual 100 mm︱tailstock adjustment 11134 mm︱tailstock travel rapid travel 0-4000 mm/min︱z-axis 15000 mm︱x-axis 1600 mm︱

---

Turning- milling- grinding center for complete machining of turbine rotors, rolls and shafts. machine is in excellent condition with following configuration: - SIEMENS Sinumerik 840 D SL Operate - sviwel axi in ram (A-Axis) - turning attachment C6 - width 84 mm - turning attachment C8 - width 100 mm - milling extension - 81 kW - angle milling head, Standard - 81 kW - angle milling head, narrow - 10 kW - universal milling head - 30 kW - milling head for milling discs (Slotter) - 81 kW - grinding attachment for external grinding - 30 kW - 3 steady bases - 2 hydrodynamic steady tops - 2 workpiece clamings for hydrodynamic steady tops - 10 exchangable bearing shells for steady tops - 1 roller steady in C-execution - 1 hydraulic workpiece release - cooling system - dust exhaust system - plastic chips exhaust - video-control - Pick-up station for 8 heads - storage place for 3 milling discs - pillar sviweling crane - 250 kg - automatic tool changing system - 102 Plätze - tool cleaning system - tool breakage monitoring - workpiece measuring system Renishaw - 2-point measuring system - complete housing - Georg Maintenance System (GMS) Basis plus vibration monitoring

turning diameter over bed 2400 mm︱turning diameter over slide rest 2000 mm︱turning length 1800 mm︱power capacity 95 kW︱max. torque on faceplate 80000 Nm︱main spindle speeds: 1-200 U/min ︱main spindle bore 150 mm︱max. workpiece weight at 540 mm 8000 kg︱faceplate diameter 2400 mm︱total power requirement 125 kW︱weight of the machine ca. 40 t︱dimensions of the machine ca. 10,4x7x4,3 m︱

---

Modernized and equipped with Siemens 840 D SL in 2014! Machine has following options: - Linear measuring system - oil cooling unit - oil-dust-exhaust - traveling splash guard - traveling operator platform - ATC with 40 stations - tool measuring device - cooling unit - chip conveyor

turning diameter over bed 4000 mm︱turning diameter over slide rest 3500 mm︱turning length 10950 mm︱turning speed range: 1-300 U/min︱power capacity 171 kW︱workpiece weight with 2 steadies 180000 kg︱max. workpiece weight between centres 75000 kg︱Total weight, approx. 350.000 kg︱dimensions of the machine ca. 28,6 x 10,8 x 4,1 m︱workpiece weight with one steady 140000 kg︱max. workpiece weight -without tailstock 10000 kg︱faceplate diameter 2200 mm︱turning speed range - C-axis 0-5 U/min︱max. torque on the working spindle ca. 7200 Nm︱tailstock - quill dia 530 mm︱quill adjustment - autom. and manual 100 mm︱tailstock adjustment 11134 mm︱tailstock travel rapid travel 0-4000 mm/min︱z-axis 15000 mm︱x-axis 1600 mm︱

---

Turning- milling- grinding center for complete machining of turbine rotors, rolls and shafts. machine is in excellent condition with following configuration: - SIEMENS Sinumerik 840 D SL Operate - sviwel axi in ram (A-Axis) - turning attachment C6 - width 84 mm - turning attachment C8 - width 100 mm - milling extension - 81 kW - angle milling head, Standard - 81 kW - angle milling head, narrow - 10 kW - universal milling head - 30 kW - milling head for milling discs (Slotter) - 81 kW - grinding attachment for external grinding - 30 kW - 3 steady bases - 2 hydrodynamic steady tops - 2 workpiece clamings for hydrodynamic steady tops - 10 exchangable bearing shells for steady tops - 1 roller steady in C-execution - 1 hydraulic workpiece release - cooling system - dust exhaust system - plastic chips exhaust - video-control - Pick-up station for 8 heads - storage place for 3 milling discs - pillar sviweling crane - 250 kg - automatic tool changing system - 102 Plätze - tool cleaning system - tool breakage monitoring - workpiece measuring system Renishaw - 2-point measuring system - complete housing - Georg Maintenance System (GMS) Basis plus vibration monitoring

turning diameter 1050 mm︱turning length 5850 mm︱control Heidenhain MANUALplus ︱turning diameter over slide rest 730 mm︱center height over square guideway 520 mm︱max. workpiece weight between centres 6000 kg︱workpiece weight in steadies max. 8000 kg ︱turning speed range 3-1250 U/min︱max. torque on faceplate 10000 Nm︱tailstock - quill dia 150 mm︱tailstock quill taper ISO 100/1:20 ︱tailstock - travel of quill 250 mm︱feed range - horizontal 1-1000 mm/min︱rapid travel - longitudinal/face 5 m/min︱spindle bore 128 mm︱weight of the machine ca. 11 t︱dimensions of the machine ca. 9x2,9x1,5 m︱

---

- with 3 steadies (Ø500, 300, 200mm) and 3 centers - incl. chip conveyor

faceplate diameter 3200 mm︱swing diameter 5100 mm︱turning height 2505 mm︱cross rail - adjustment 1500 mm︱max. ram stroke 1250 mm︱slide adjustment 2000 mm︱control Siemens 8 T ︱tool changer 16 STK ︱table load 60 t︱faceplate turning speed range -stepless- 0,8-100 U/min︱feed 0,0 1-1000 mm/min︱rapid traverse 6000 mm/min︱drive of main spindle 75 kW︱weight of the machine ca. 70 t︱dimensions of the machine ca. 9,3 x 6,1 x 6,0 m︱

---

machine is in an excellent condition!! with div. acessories (photos available) machine can be equipped with latest electrics and Siemens CNC control SINUMERIK 840D sl for additional costs.

bore capacity in steel (diameter) 50 mm︱max. pitch circle 4300 mm︱number of spindles 1 ︱Control Heidenhain TNC 426 ︱min. dia. 2100 mm︱table diameter 4500 mm︱weight of the machine ca. 22 t︱dimensions of the machine ca. 6 x 6 x 4 m︱

---

- CNC-control Heidenhain - internal cooling distance between table and spindle 630mm boring stroke 380mm

spindle diameter 130 mm︱x-travel 6920 mm︱y-travel 2500 mm︱z-travel 900 mm︱milling spindle / ram ISO 50 mm︱bore spindle turning speed range 6-1200 U/min︱electrics - voltage/frequency 380/50 V/Hz︱Control Heidenhain TNC 355 ︱weight of the machine ca. 35 t︱dimensions of the machine ca. 9,7 x 4,0 x 6,0 m︱

---

- incl. clamping plate area 10x4,4 m - incl. moveable counter steady - incl. 2 clamping prism stands , 1 moveable

spindle diameter 110 mm︱x-travel 900 mm︱y-travel 600 mm︱cross rail adjustment - vertical 635 mm︱quill travel 200 mm︱column daylight 950 mm︱max. distance between table and spindle-nose 15 - 850 mm︱table surface area 1020 x 860 mm︱table load 800 kg︱speeds 10 - 2500 U/min︱adjustment speed 5 - 2500 mm/min︱tool taper ISO 40 ︱electrics - voltage/frequency 380/50 V/Hz︱total power requirement 8 kW︱weight of the machine ca. 7 t︱dimensions of the machine ca. 4,9 x 2,9 x 3 m︱

---

- 2 axis digital-readout ELESTA - with misc. tool holders

x-travel 600 mm︱y-travel 500 mm︱z-travel 500 mm︱turning speeds 15000 1/min︱tool adaptor HSK 63A ︱tool magazin: 40 Pos.︱spindle 34,5 kW︱feeds x/y/z -stepless 60.000 mm/min︱weight of the machine ca. 9 t︱dimensions of the machine ca. 5x3x3 m︱torque 110 Nm︱tool changing time 1,7 sec︱angle of table min./max. +/- 120 Grad︱rotary table diameter 600 mm︱circular table speeds 100 U/min︱

---

Machine is used in the laboratory of an University for the prototype machining of aluminium parts. Very less working hours. vise is not scope of supply. * Siemens Sinumerik 840D SL with Shopmill incl. post processor for CAD-CAM * 5-axis simultanously * internal cooling 20 bar * manual measuring probe * 8 tool holder * chip conveyor

bore capacity in steel (diameter) 55,0 mm︱arm length 1750 mm︱workpiece height max. 1630 mm︱turning speeds 19 - 1320 U/min︱bore spindles - Morse Taper 5 MK︱engine output 5,5 kW︱weight 5 t︱range L-W-H 2,4 x 1,0 x 3,55 mm︱feed movement 475 mm︱floor plate size: 1650x1000 mm︱feeds 0,07-2,9 mm/U︱

---

bore capacity in steel (diameter) 50,0 mm︱arm length 1.350 mm︱workpiece height max. 1630 mm︱turning speeds 19 - 1320 U/min︱bore spindles - Morse Taper 5 MK︱engine output 5,5 kW︱weight 5 t︱range L-W-H 2,4 x 1,0 x 3,55 mm︱feed movement 475 mm︱floor plate size: 1650x1000 mm︱feeds 0,07-2,9 mm/U︱

---

bore capacity in steel (diameter) 40 mm︱arm length 1250 mm︱workpiece height max. 1000 mm︱turning speeds 40-1700 U/min︱bore spindles - Morse Taper 4 MK︱engine output 4,2 kW︱weight 3,5 t︱range L-W-H 2 x 1,0 x 2,9 mm︱feed movement 325 mm︱floor plate size: 1500x910 mm︱feeds 0,12-1,2 mm/U︱

---

- sviweling cube - boring chuck + misc. tool holder - tool holder stand

spindle diameter 200 mm︱x-travel 10000 mm︱y-travel 3000 mm︱ram stroke 1600 mm︱dimension of the ram 520 x 520 mm︱tool adaptor ISO 60 ︱bore spindle stroke 2000 mm︱bore spindle turning speed range 1,6 - 630 U/min︱spindle motor 83 kW︱bore feed range 0,63 - 2500 mm/U︱milling feed range 0,63 - 5000 mm/min︱electrics - voltage/frequency 380/50 V/Hz︱Control ︱total power requirement 85 kW︱weight of the machine ca. 86 t︱dimensions of the machine ca. 13,8 x 6 x 8,3 m︱

---

photos show machine first at location, then as is in our warehouse.

spindle diameter 160 mm︱x-travel 12000 mm︱y-travel 4000 mm︱bore spindle stroke 700 mm︱ram stroke 800 ︱spindle taper ISO 50 ︱spindle turning speed - stepless 2,5 - 1250 U/min︱feed stepless 0 - 10000 mm/min︱power capacity 65 kW︱rapid traverse 10 m/min︱weight of the machine ca. 115 t︱dimensions of the machine ca. 21 x 14 x 8 m︱

---

- Modernized in 2007 with CNC-control SIEMENS 840 D sl - integrated rotary table Ø 2500 mm, in clamping area aprox. 6x4 m inserted - chip conveyor - misc. heads

spindle diameter 200 mm︱x-travel 6000 mm︱y-travel 3000 mm︱Control Siemens 850 ︱bore slide stroke 2000 mm︱ram stroke 1600 ︱dimension of the ram 520x520 mm︱taper ISO 60 ︱bore spindle turning speed range 1,6-630 U/min︱spindle motor 83 kW︱bore feed range 0,63-2500 mm/U︱milling feed range 0,63-5000 mm/min︱electrics - voltage/frequency 380/50 V/Hz︱total power requirement 100 kW︱weight of the machine ca. 80 t︱dimensions of the machine ca. 12x6x8,3 m︱

---

spindle diameter 130 mm︱x-travel 2000 mm︱y-travel 1600 mm︱z-travel 1600 mm︱w-travel 700 mm︱spindle taper MT ︱reus 14-1000 U/min︱table surface area 2200x1800 mm︱weight of the machine ca. 20 t︱dimensions of the machine ca. 6x4,5x4,5 m︱

---

spindle diameter 105 mm︱x-travel 1700 mm︱y-travel 1250 mm︱z-travel 1250 mm︱w-travel 700 mm︱spindle turning speed range 10-1000 U/min︱digital measuring device for 2 axis Sony ︱dimensions of the machine ca. 5x4x3 m︱weight of the machine ca. 15000 kg︱

---

x-travel 17700 mm︱y-travel 4755 mm︱z-travel 800 mm︱milling width 3450 mm︱distance table - vertical milling spindle 3682 mm︱table height over floor 500 mm︱spindle diameter in front bearing 200 mm︱turning speed range 12 - 450 U/min︱tool taper ISO 60 ︱axial adjustment of the spindle slide 800 mm︱creep feed 5 und 50 mm/min︱feed stepless 10 - 3000 mm/min︱cross adjustment of cross beam milling head 4745 ︱rapid traverse 2 m/min︱creep feed 3 und 30 mm/min︱feed stepless 6 - 2000 mm/min︱rapid traverse 2 m/min︱creep feed 3 und 30 mm/min︱feed stepless 6 - 2000 mm/min︱vertical adjustment of cross beam 3682 mm︱

---

+ electrically renewed including cabinet, cabling and motors and equipped with a SIEMENS 840 C in 1999. + incl. 16 milling heads and misc.tools

x-travel 16000 mm︱y-travel 5000 mm︱z-travel 2450 mm︱w-travel 400 mm︱table: 2 x 7500 x 3000 ︱double table 15.700 x 3000 mm︱table load 150 t︱max. passage 3250 mm︱diameter of quill 320 mm︱spindle turning speed range 6-200, 200-600 U/min︱transmission ratio 2 ︱drive capacity - spindle motor 95 kW︱spindle taper ISO 60 ︱electrics - voltage/frequency 380/50 V/Hz︱Control Siemens 840 D SL ︱weight of the machine ca. 260 t︱dimensions of the machine ca. 34.000x10.000x11,500 m︱angular milling head 10x ︱

---

Retrofit in 2016: - electrics including cabling and cabinet new - new CNC-control SIEMENS 840 D Solution line - hydrostatic guideways for table with 6 pumps and 2 pumps for tank - change from DC to AC (motors) - all guideways geometrically overhauled (laser measured) - modifcation cross beam to gantry type - all guideway covers new - delivery end of October 2016 - spindle drive changed into 3-phase current - misc. milling heads - 10 pcs. - especially for diesel-engines + CE-certified in June 2017 + inspectable under power +

x-travel 625 mm︱y-travel 525 mm︱z-travel 455 mm︱table-size 900x500 mm︱quill stroke 80 mm︱tool taper SK 40 ︱feeds x/y/z -stepless 1-4000 mm/min︱rapid traverse 10000 mm/min︱milling head -swivable +/- 45 °︱weight of the machine ca. 4 t︱dimensions of the machine ca. 4,2x3,6x2,4 m︱CNC Control Heidenhain TNC 407 ︱

---

x-travel 700 mm︱y-travel 500 mm︱z-travel 450 mm︱table surface area 900 x 500 mm︱spindle stroke 100 mm︱tool taper ISO 40 ︱turning speed range 20 - 3150 U/min︱feeds - cross 1 - 3000 mm/min︱feeds - longitudinal 1 - 3000 mm/min︱feed power in the axis x + z 8.000 N︱feed power in the axis y 24.000 N︱rapid traverse in the axis x + y 6 m/min︱rapid traverse in axis z 11,4 m/min︱total power requirement 40 kVA︱weight of the machine ca. 3,3 t︱dimensions of the machine ca. 3,8 x 3,6 x 2,2 m︱electrics - voltage/frequency 380 / 50 V/Hz︱CNC Control Maho CNC 432 ︱

---

Continous Path Control Philips CNC 432
