          Copying Lathe

          used  Copying Lathe HEYLIGENSTAEDT HEYCOP 2/2000


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00282 · Copying Lathe

          HEYLIGENSTAEDT - HEYCOP 2/2000 - - 1960 -

          Technical details
          turning diameter over slide rest 250 mm︱centre distance 2000 mm︱copying travel longitudinal 2000 mm︱turning speeds 22 - 1120 U/min︱voltage 380 V︱total power requirement 11 kW︱weight of the machine ca. 3,65 t︱dimensions of the machine ca. 4 x 1,5 x 1,5 m︱
          We quote a copying lathe of type HEYLIGENSTAEDT HEYCOP 2/2000. This machine is in good running conditions and comes from company in our neighbourship. The quality and the shape of machine is in good manner. There can be turned parts up to dia. 250mm and lenght 2000mm, with chuck or between centers. The machine has copying devoice and is suitable for turning of quantity of same parts in short time. With the machine will be delivered chuck, lynette, oil bassin with high pressure pump, manual in German language and separate OUT-Button. Come for inspection to our company in Giebelstadt, about 80min from FRANKFURT AIRPORT.
            turning diameter over slide rest 250 mm
            centre distance 2000 mm
            copying travel longitudinal 2000 mm
            turning speeds 22 - 1120 U/min
            voltage 380 V
            total power requirement 11 kW
            weight of the machine ca. 3,65 t
            dimensions of the machine ca. 4 x 1,5 x 1,5 m
            Description :
            We quote a copying lathe of type HEYLIGENSTAEDT HEYCOP 2/2000. This machine is
            in good running conditions and comes from company in our neighbourship. The
            quality and the shape of machine is in good manner. There can be turned parts
            up to dia. 250mm and lenght 2000mm, with chuck or between centers. The machine
            has copying devoice and is suitable for turning of quantity of same parts in
            short time. With the machine will be delivered chuck, lynette, oil bassin with
            high pressure pump, manual in German language and separate OUT-Button. Come for
            inspection to our company in Giebelstadt, about 80min from FRANKFURT AIRPORT.
          Datasheet
          Request / Contact

          Radial Drilling Machine - Universal

          used  Radial Drilling Machine - Universal MAS VR2


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00316 · Radial Drilling Machine - Universal

          MAS - VR2 - - 1961 -

          Technical details
          bore capacity in steel (diameter) 30 mm︱arm length 815 mm︱workpiece height max. ca. 1500 mm︱bore depth 240 mm︱spindle taper MT 3 ︱connected load frequency 380V 50Hz ︱total power requirement 2,6 kW︱weight of the machine ca. 2 t︱dimensions of the machine ca. 1,7 x 0,8 x 2,5 m︱
          We offer a radial drilling machine from the manufacturer MAS of type VR2. The machine is in a good, ready-to-run condition and can be inspected under power. It is first hand from a neighboring Bavarian job shop. The machine is supplied with a cooling oil pump and a pitching cube. Price is free loaded on truck. ome to a demonstration of the machine in our warehouse in Giebelstadt, about 80min. from Frankfurt airport.
            bore capacity in steel (diameter. 30 mm
            arm length 815 mm
            workpiece height max. ca. 1500 mm
            bore depth 240 mm
            spindle taper MT 3
            connected load frequency 380V 50Hz
            total power requirement 2,6 kW
            weight of the machine ca. 2 t
            dimensions of the machine ca. 1,7 x 0,8 x 2,5 m
            Description :
            We offer a radial drilling machine from the manufacturer MAS of type VR2. The
            machine is in a good, ready-to-run condition and can be inspected under power.
            It is first hand from a neighboring Bavarian job shop. The machine is supplied
            with a cooling oil pump and a pitching cube.

            Price is free loaded on truck.

            ome to a demonstration of the machine in our warehouse in Giebelstadt, about
            80min. from Frankfurt airport.
          2.525 €
          Datasheet
          Request / Contact

          Gear Hobbing Machine - Horizontal

          used  Gear Hobbing Machine - Horizontal MIKRON M79


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00271 · Gear Hobbing Machine - Horizontal

          MIKRON - M79 - - 1970 -

          Technical details
          max. wheel diameter 40 mm︱gear width 28 mm︱max. module 1 ︱min. module 0 ︱total power requirement 1 kW︱weight of the machine ca. 200 kg︱dimensions of the machine ca. 1 x 1 x 1,5 m︱
          We quote a conventional gear hobber of type MIKRON M79. This machine is in good condition and can be used for manual hobbing of smal straight gears. This machine can be inspected in our storage in Würzburg, nearby Frankfurt. There are no accessoires with the machine. No changing wheels and also no cooling pump. Come for inspection to Würzburg, about 80min. from FRANKFURT AIRPORT
            max. wheel diameter 40 mm
            gear width 28 mm
            max. module 1
            total power requirement 1 kW
            weight of the machine ca. 200 kg
            dimensions of the machine ca. 1 x 1 x 1,5 m
            Description :
            We quote a conventional gear hobber of type MIKRON M79. This machine is in
            good condition and can be used for manual hobbing of smal straight gears. This
            machine can be inspected in our storage in Würzburg, nearby Frankfurt. There
            are no accessoires with the machine. No changing wheels and also no cooling
            pump. Come for inspection to Würzburg, about 80min. from FRANKFURT AIRPORT
          Datasheet
          Request / Contact
          used  Gear Hobbing Machine - Horizontal MIKRON M79


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00252 · Gear Hobbing Machine - Horizontal

          MIKRON - M79 - - 1970 -

          Technical details
          max. wheel diameter 40 mm︱gear width 28 mm︱max. module 1 ︱min. module 0 ︱total power requirement 1 kW︱weight of the machine ca. 200 kg︱dimensions of the machine ca. 1 x 1 x 1,5 m︱
          We quote a conventional gear hobber of type MIKRON M79. This machine is in good condition and can be used for manual hobbing of smal straight gears. This machine can be inspected in our storage in Würzburg, nearby Frankfurt. There are no accessoires with the machine. No changing wheels and also no cooling pump with bassin.
            max. wheel diameter 40 mm
            gear width 28 mm
            max. module 1
            total power requirement 1 kW
            weight of the machine ca. 200 kg
            dimensions of the machine ca. 1 x 1 x 1,5 m
            Description :
            We quote a conventional gear hobber of type MIKRON M79. This machine is in
            good condition and can be used for manual hobbing of smal straight gears. This
            machine can be inspected in our storage in Würzburg, nearby Frankfurt. There
            are no accessoires with the machine. No changing wheels and also no cooling
            pump with bassin.
          Datasheet
          Request / Contact

          Gear Noise under Load Testing Machine

          used  Gear Noise under Load Testing Machine HURTH ZP 300


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00268 · Gear Noise under Load Testing Machine

          HURTH - ZP 300 - - 2000 -

          Technical details
          max. wheel diameter 300 mm︱centre distance 500 mm︱max. module 6 mm︱min. module 0,1 mm︱total power requirement 35 kW︱weight of the machine ca. 1,5 t︱dimensions of the machine ca. 2,5 x 1,0 x 1,7 m︱brake tailstock ︱workpiece steady rest
          The gear noise tester HURTH ZP 300 is used for noise tests of external gears with chance of error detection. Our machine is disassembled in our stock. The machine is in good working condition and can be overtaken now. Come and inspect the tester in Giebelstadt, nearby 80 min to Frankfurt airport. Description: This tester HURTH ZP 300 was in ´2000 complete mechanical overhauled and modernized by company FORTUNA (grinding machine specialist) with: - 2 new servo motors directly adapted to spindles, type BAUMÜLLER DS 100-S (17kW, 4000rpmn, 36Nm) - 2 new spindles of typeFORTUNA FIVY 90RL 190 HSK-40.301 for max. 6000rpm - 2 new couplings between servo and spindle of type KTR - HEIDENHAIN linear encoder for measuring of axial shift - HEIDENHAIN linear encoder LS 476 ML120mm for measuring of radial shift - 4 new BRUCKNER centers With this machine there is no controlling unit. So the machine is predestinated for customer, who wants to install new controller! Of this type we have 2 similar machines in stock.
            max. wheel diameter 300 mm
            centre distance 500 mm
            max. module 6 mm
            min. module 0,1 mm
            total power requirement 35 kW
            weight of the machine ca. 1,5 t
            dimensions of the machine ca. 2,5 x 1,0 x 1,7 m
            Description :
            The gear noise tester HURTH ZP 300 is used for noise tests of external gears
            with chance of error detection. Our machine is disassembled in our stock. The
            machine is in good working condition and can be overtaken now. Come and inspect
            the tester in Giebelstadt, nearby 80 min to Frankfurt airport.

            Description:
            This tester HURTH ZP 300 was in ´2000 complete mechanical overhauled and
            modernized by company FORTUNA (grinding machine specialist) with:
            - 2 new servo motors directly adapted to spindles, type BAUMÜLLER DS 100-S
            (17kW,
            4000rpmn, 36Nm)
            - 2 new spindles of typeFORTUNA FIVY 90RL 190 HSK-40.301 for max. 6000rpm
            - 2 new couplings between servo and spindle of type KTR
            - HEIDENHAIN linear encoder for measuring of axial shift
            - HEIDENHAIN linear encoder LS 476 ML120mm for measuring of radial shift
            - 4 new BRUCKNER centers

            With this machine there is no controlling unit. So the machine is predestinated
            for customer, who wants to install new controller!

            Of this type we have 2 similar machines in stock.
          Datasheet
          Request / Contact
          used  Gear Noise under Load Testing Machine HURTH ZP 300


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00269 · Gear Noise under Load Testing Machine

          HURTH - ZP 300 - - 2000 -

          Technical details
          max. wheel diameter 300 mm︱centre distance 500 mm︱max. module 6 mm︱min. module 0,1 mm︱total power requirement 35 kW︱weight of the machine ca. 1,5 t︱dimensions of the machine ca. 2,5 x 1,0 x 1,7 m︱brake tailstock ︱workpiece steady rest
          The gear noise tester HURTH ZP 300 is used for noise tests of external gears with chance of error detection. Our machine is disassembled in our stock. The machine is in good working condition and can be overtaken now. Come and inspect the tester in Giebelstadt, nearby 80 min to Frankfurt airport. Description: This tester HURTH ZP 300 was in ´2000 complete mechanical overhauled and modernized by company FORTUNA (grinding machine specialist) with: - 2 new servo motors directly adapted to spindles, type BAUMÜLLER DS 100-S (17kW, 4000rpmn, 36Nm) - 2 new spindles of typeFORTUNA FIVY 90RL 190 HSK-40.301 for max. 6000rpm - 2 new couplings between servo and spindle of type KTR - HEIDENHAIN linear encoder for measuring of axial shift - HEIDENHAIN linear encoder LS 476 ML120mm for measuring of radial shift - 4 new BRUCKNER centers With this machine there is no controlling unit. So the machine is predestinated for customer, who wants to install new controller! Of this type we have 2 similar machines in stock.
            max. wheel diameter 300 mm
            centre distance 500 mm
            max. module 6 mm
            min. module 0,1 mm
            total power requirement 35 kW
            weight of the machine ca. 1,5 t
            dimensions of the machine ca. 2,5 x 1,0 x 1,7 m
            Description :
            The gear noise tester HURTH ZP 300 is used for noise tests of external gears
            with chance of error detection. Our machine is disassembled in our stock. The
            machine is in good working condition and can be overtaken now. Come and inspect
            the tester in Giebelstadt, nearby 80 min to Frankfurt airport.

            Description:
            This tester HURTH ZP 300 was in ´2000 complete mechanical overhauled and
            modernized by company FORTUNA (grinding machine specialist) with:
            - 2 new servo motors directly adapted to spindles, type BAUMÜLLER DS 100-S
            (17kW,
            4000rpmn, 36Nm)
            - 2 new spindles of typeFORTUNA FIVY 90RL 190 HSK-40.301 for max. 6000rpm
            - 2 new couplings between servo and spindle of type KTR
            - HEIDENHAIN linear encoder for measuring of axial shift
            - HEIDENHAIN linear encoder LS 476 ML120mm for measuring of radial shift
            - 4 new BRUCKNER centers

            With this machine there is no controlling unit. So the machine is predestinated
            for customer, who wants to install new controller!

            Of this type we have 2 similar machines in stock.
          Datasheet
          Request / Contact

          Cylindrical Grinding Machine

          used  Cylindrical Grinding Machine TITAN RU350.1x1000


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00317 · Cylindrical Grinding Machine

          TITAN - RU350.1x1000 - - 1983 -

          Technical details
          grinding diameter 350 mm︱grinding length 1000 mm︱centre height 200 mm︱connected load frequency 3x380V 50Hz ︱total power requirement 7 kW︱weight of the machine ca. 3,5 t︱dimensions of the machine ca. 3,3x2,0x1,6 m︱
          We offer an external cylindrical grinding machine from the manufacturer TITAN with type RU 350.1 x 1000. The machine was built under license from FORTUNA in Romania.The machine was used until now at a neighboring Bavarian job shop. The machine is complete and was in use until 2021. Come and see the machine in our warehouse in Giebelstadt, about 80min. from Frankfurt airport.
            grinding diameter 350 mm
            grinding length 1000 mm
            centre height 200 mm
            connected load frequency 3x380V 50Hz
            total power requirement 7 kW
            weight of the machine ca. 3,5 t
            dimensions of the machine ca. 3,3x2,0x1,6 m
            Description :
            We offer an external cylindrical grinding machine from the manufacturer TITAN
            with type RU 350.1 x 1000. The machine was built under license from FORTUNA in
            Romania.The machine was used until now at a neighboring Bavarian job shop.

            The machine is complete and was in use until 2021.

            Come and see the machine in our warehouse in Giebelstadt, about 80min. from
            Frankfurt airport.
          8.495 €
          Datasheet
          Request / Contact

          Hob Sharpening Machine

          used  Hob Sharpening Machine KLINGELNBERG AGW 420


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00242 · Hob Sharpening Machine

          KLINGELNBERG - AGW 420 - - 1970 -

          Technical details
          grinding diameter 100 - 420 mm︱grinding length 600 mm︱module 0,5 - 50 ︱total power requirement 14 kW︱weight of the machine ca. 8 t︱dimensions of the machine ca. 3,0 x 2,0 x 2,0 m︱max.helical angle +/- 45° °︱clamping slot depth - max. 100 mm︱T-slot pitch 50" bis unendlich mm︱max. stroke of grinding wheel 800 mm︱grinding wheel diameter 240 - 350 mm︱grinding wheel turining speeds 1.300 - 1.900 U/min︱grinding wheel speed 0 - 12 m/min︱taper in workpiece headstock ISO40
          We quote a hob sharpener in running condition with all neccessary attachment of type KLINGELNBERG AGW 420. This machine can sharpen hobs and cutters up to diameter 420 mm and width up to 600 mm with helic angle up to 45° under cooling fluid, wet. With the machine are: - control cabin - cooling unit - hydraulic unit - exhausting unit If requested, we can quote additional geometric protocol of machine, partial overhauling or modernization by KLINGELNBERG specialists according to your need and at your charge. Come for inspection.
            grinding diameter 100 - 420 mm
            grinding length 600 mm
            module 0,5 - 50
            total power requirement 14 kW
            weight of the machine ca. 8 t
            dimensions of the machine ca. 3,0 x 2,0 x 2,0 m
            max.helical angle +/- 45° °
            clamping slot depth - max. 100 mm
            T-slot pitch 50" bis unendlich mm
            max. stroke of grinding wheel 800 mm
            grinding wheel diameter 240 - 350 mm
            grinding wheel turining speeds 1.300 - 1.900 U/min
            grinding wheel speed 0 - 12 m/min
            taper in workpiece headstock ISO40
            Description :
            We quote a hob sharpener in running condition with all neccessary attachment of type KLINGELNBERG AGW 420. This machine can sharpen hobs and cutters up to diameter 420 mm and width up to 600 mm with helic angle up to 45° under cooling fluid, wet. With the machine are: - control cabin - cooling unit - hydraulic unit - exhausting unit If requested, we can quote additional geometric protocol of machine, partial overhauling or modernization by KLINGELNBERG specialists according to your need and at your charge. Come for inspection.
          Datasheet
          Request / Contact

          Sharpening Machine

          used  Sharpening Machine MIKRON A60


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00315 · Sharpening Machine

          MIKRON - A60 - - 1979 -

          Technical details
          grinding diameter 100 mm︱grinding length 100 mm︱connected load frequency 380V 50Hz ︱turning speeds 4000 / 6200 U/min︱total power requirement 1 kW︱weight of the machine ca. 470 kg︱dimensions of the machine ca. 70 x 71 x 110 cm︱
          We offer a freshly overhauled hob sharpener from MIKRON of type A60. The machine was completely repaired in 2021 by MIKRON specialist fitters for about € 10,000. The machine can be demonstrated under power i our warehouse. It has the machine number 60.30.01 and is in excellent condition for immediate use. The machine is predestined for sharpening smaller hobs, tooth form cutters and worm cutters for the fine gear industry. The machine is equipped with a milling arbor for a bore diameter of 10mm. The operating instructions and electrical circuit diagrams are also available. Additional accessories can be obtained from a Swiss specialist company. Come to our factory in Giebelstadt about 80 min. from Frankfurt airport
            grinding diameter 100 mm
            grinding length 100 mm
            connected load frequency 380V 50Hz
            turning speeds 4000 / 6200 U/min
            total power requirement 1 kW
            weight of the machine ca. 470 kg
            dimensions of the machine ca. 70 x 71 x 110 cm
            Description :
            We offer a freshly overhauled hob sharpener from MIKRON of type
            A60. The machine was completely repaired in 2021 by MIKRON specialist fitters
            for about € 10,000. The machine can be demonstrated under power i our
            warehouse. It has the machine number 60.30.01 and is in excellent condition
            for immediate use.

            The machine is predestined for sharpening smaller hobs,
            tooth form cutters and worm cutters for the fine gear industry.

            The machine is equipped with a milling arbor for a bore diameter of 10mm.
            The operating instructions and electrical circuit diagrams are also available.

            Additional accessories can be obtained from a Swiss specialist company.


            Come to our factory in Giebelstadt about 80 min. from Frankfurt airport
          Datasheet
          Request / Contact

          Super Finishing Machine

          used  Super Finishing Machine SUPFINA 455.8


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00291 · Super Finishing Machine

          SUPFINA - 455.8 - - 1995 - SIEMENS S5-115U, Typ 944B

          Technical details
          workpiece diameter ca. 0 - 100 mm︱swing diameter ca. 150 mm︱workpiece length 455 mm︱Control SIEMENS S5-115U, Typ 944B ︱connected load frequency 3x400V 50Hz ︱stroke 40 mm︱total power requirement 10 kW︱weight of the machine ca. 2,2 t︱dimensions of the machine ca. 5,9 x 7,7 x 2,4 m︱
          We quote a superfinish machiine of type SUPFINA 455 with automatic loading system. This machine number 300.805 from ´1995 is in good shape and can be inspected dismantled in our company in Giebelstadt, about 80min. from FRANKFURT AIRPORT. With the machine can be realized roughness of Rz 1,0µm, form 2,0µm convex and parallelity of 2,0µm. The machine is equipped with superfinish attachment of type SUPFINA 200 with 4 SF stone guides. They are on guide and can be installed in length up to 455mm. The workpieces are hold on 2 driven rollers. The axe distance of rollers can be changed and adapted to diameter of workpiece. With the machine is an loading and unloading portal from SK-Hydroautomation of type 5192 including controlling unit SIEMENS WS 400-22 and fences. The former conveyor belt from EWAB is not with the machine. All documentatio in German language is with the machine. Come for inspection.
            workpiece diameter ca. 0 - 100 mm
            swing diameter ca. 150 mm
            workpiece length 455 mm
            Control SIEMENS S5-115U, Typ 944B
            connected load frequency 3x400V 50Hz
            stroke 40 mm
            total power requirement 10 kW
            weight of the machine ca. 2,2 t
            dimensions of the machine ca. 5,9 x 7,7 x 2,4 m
            Description :
            We quote a superfinish machiine of type SUPFINA 455 with automatic loading
            system. This machine number 300.805 from ´1995 is in good shape and can be
            inspected dismantled in our company in Giebelstadt, about 80min. from FRANKFURT
            AIRPORT. With the machine can be realized roughness of Rz 1,0µm, form 2,0µm
            convex and parallelity of 2,0µm.
            The machine is equipped with superfinish attachment of type SUPFINA 200 with 4
            SF stone guides. They are on guide and can be installed in length up to 455mm.
            The workpieces are hold on 2 driven rollers. The axe distance of rollers can be
            changed and adapted to diameter of workpiece.

            With the machine is an loading and unloading portal from SK-Hydroautomation of
            type 5192 including controlling unit SIEMENS WS 400-22 and fences. The former
            conveyor belt from EWAB is not with the machine.

            All documentatio in German language is with the machine.

            Come for inspection.
          Datasheet
          Request / Contact

          Band Saw - Vertical

          used  Band Saw - Vertical SAMUR S-400-VA


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-000314 · Band Saw - Vertical

          SAMUR - S-400-VA - - 1990 -

          Technical details
          roll diameter 400 mm︱throat 380 mm︱workpiece height 300 mm︱total power requirement 2 kW︱weight of the machine ca. 360 kg︱dimensions of the machine ca. 1,1 x 0,7 x 2,1 m︱
          We provide a vertical band saw of brand SAMUR / Spain. The machine of type S-400-VA is in good condition. Come for inspection to our storage in Giebelstadt, about 80min. from Frankfurt airport.
            roll diameter 400 mm
            throat 380 mm
            workpiece height 300 mm
            total power requirement 2 kW
            weight of the machine ca. 360 kg
            dimensions of the machine ca. 1,1 x 0,7 x 2,1 m
            Description :
            We provide a vertical band saw of brand SAMUR / Spain. The machine of type
            S-400-VA is in good condition.

            Come for inspection to our storage in Giebelstadt, about 80min. from Frankfurt
            airport.
          Datasheet
          Request / Contact

          Broaching Machine-Internal - Vertical

          used  Broaching Machine-Internal - Vertical FORST RSIA 2


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00292 · Broaching Machine-Internal - Vertical

          FORST - RSIA 2 - - 1970 -

          Technical details
          pulling force - max. 2 t︱stroke length max. 800 mm︱Table dimensions 360 x 320 mm︱cutting speed 1,5 m/min︱return speed 3,0 m/min︱power requirement 3 kW︱coolant ︱voltage 380 V︱bore diameter 70 mm︱total power requirement 3 kW︱weight of the machine ca. 1200 kg︱dimensions of the machine ca. 1,2 x 0,9 x 2,7 m︱
          We quote an older, but complete and running vertical broaching machine in highest stability of typ FORST RSIA 2. This machine with 6,5 HP has a vertical stoke of 800mm. The table is 360 x 320 mm with bore of 70mm. This machine is predestinated for broaching round inner profiles with small depth and small width. With its hydraulic it can be used for high quantities. This machine is from 1st hand out of job shop in neighborship to our company. Come for inspection to our location in Giebelstadt, about 80 min. from FRANKFURT AIRPORT.
            pulling force - max. 2 t
            stroke length max. 800 mm
            Table dimensions 360 x 320 mm
            cutting speed 1,5 m/min
            return speed 3,0 m/min
            power requirement 3 kW
            voltage 380 V
            bore diameter 70 mm
            total power requirement 3 kW
            weight of the machine ca. 1200 kg
            dimensions of the machine ca. 1,2 x 0,9 x 2,7 m
            Description :
            We quote an older, but complete and running vertical broaching machine in
            highest stability of typ FORST RSIA 2. This machine with 6,5 HP has a vertical
            stoke of 800mm. The table is 360 x 320 mm with bore of 70mm.

            This machine is predestinated for broaching round inner profiles with small
            depth and small width. With its hydraulic it can be used for high quantities.

            This machine is from 1st hand out of job shop in neighborship to our company.
            Come for inspection to our location in Giebelstadt, about 80 min. from
            FRANKFURT AIRPORT.
          Datasheet
          Request / Contact

          Measuring system

          used  Measuring system AVL 4390 G004


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00314 · Measuring system

          AVL - 4390 G004 - - 2001 -

          Technical details
          voltage 230V 50/60Hz V︱total power requirement 1 kW︱weight of the machine ca. 70 kg︱dimensions of the machine ca. 50x50x50 cm︱
          We dan deliver a opacimeter of brand AVL and type AVL 4390 G004 in very good condition. The tester is equipped with probe tube and wire and manual. With the tester can be measured in gases or fluids particles, especially for Diesel. With the tester is no controller and no software! We have 2 units in our storage. Come for inspection to Giebelstadt, about 80min. from Frankfurt airport.
            voltage 230V 50/60Hz V
            total power requirement 1 kW
            weight of the machine ca. 70 kg
            dimensions of the machine ca. 50x50x50 cm
            Description :
            We dan deliver a opacimeter of brand AVL and type AVL 4390 G004 in very good
            condition. The tester is equipped with probe tube and wire and manual.

            With the tester can be measured in gases or fluids particles, especially for
            Diesel.

            With the tester is no controller and no software!

            We have 2 units in our storage. Come for inspection to Giebelstadt, about
            80min. from Frankfurt airport.
          Datasheet
          Request / Contact

          Profile projector

          used  Profile projector HAUSER 215 K


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00279 · Profile projector

          HAUSER - 215 K - - 1990 -

          Technical details
          amplification -fold 20 x ︱workpiece height max. 200 mm︱glass plate - dimensions 60 x 50 cm︱radial slide travel 50 mm︱maximum axial offset 25 mm︱Vertikal stroke 80 mm︱total power requirement 1 kW︱weight of the machine ca. 200 kg︱dimensions of the machine ca. 60 x 100 x 220 cm︱
          We quote a optical profile projector of type HAUSER 215K, machine no. 2260-266 with 2-axe digital display. The tester is in good shape. This projector is equipped with cross table for radial travel of 25mm and axial travel of +/- 25mm. The height adjustment is 80mm. There are 2 linear encoder from MSA type RSI. Both are connected to digital display of type R.S.F. type Z-502. The projector is complete running and can be inspected under power in our storage. Come for inspection to Giebelstadt, about 80min from Frankfurt airport. Attachment: The tester has an enlargement lense of factor 20x integrated. The unit has a hood with curtain. Actually we have some different projectors in warehouse. So come and you can select the suitable unit for your need.
            amplification -fold 20 x
            workpiece height max. 200 mm
            glass plate - dimensions 60 x 50 cm
            radial slide travel 50 mm
            maximum axial offset 25 mm
            Vertikal stroke 80 mm
            total power requirement 1 kW
            weight of the machine ca. 200 kg
            dimensions of the machine ca. 60 x 100 x 220 cm
            Description :
            We quote a optical profile projector of type HAUSER 215K, machine no. 2260-266
            with 2-axe digital display. The tester is in good shape. This projector is
            equipped with cross table for radial travel of 25mm and axial travel of +/-
            25mm. The height adjustment is 80mm. There are 2 linear encoder from MSA type
            RSI. Both are connected to digital display of type R.S.F. type Z-502. The
            projector is complete running and can be inspected under power in our
            storage. Come for inspection to Giebelstadt, about 80min from Frankfurt airport.


            Attachment:
            The tester has an enlargement lense of factor 20x integrated.
            The unit has a hood with curtain.

            Actually we have some different projectors in warehouse. So come and you can
            select the suitable unit for your need.
          Datasheet
          Request / Contact
          used  Profile projector HAUSER 215 K


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00278 · Profile projector

          HAUSER - 215 K - - 1980 -

          Technical details
          amplification -fold 20 x ︱workpiece height max. 200 mm︱glass plate - dimensions 60 x 50 cm︱radial slide travel 50 mm︱maximum axial offset 25 mm︱Vertikal stroke 80 mm︱total power requirement 1 kW︱weight of the machine ca. 200 kg︱dimensions of the machine ca. 60 x 100 x 220 cm︱
          We quote a optical profile projector of type HAUSER 215K, machine no. 1635-164 with 2-axe digital display. The tester is in good shape. This projector is equipped with cross table for radial travel of 25mm and axial travel of +/- 25mm. The height adjustment is 80mm. There are 2 linear encoder from MSA type RSI. Both are connected to digital display of type R.S.F. type Z-502. The projector is complete running and can be inspected under power in our storage. Come for inspection to Giebelstadt, about 80min from Frankfurt airport. Attachment: The tester has an enlargement lense of factor 20x and 10x integrated. The unit has a hood with curtain. Actually we have some different projectors in warehouse. So come and you can select the suitable unit for your need.
            amplification -fold 20 x
            workpiece height max. 200 mm
            glass plate - dimensions 60 x 50 cm
            radial slide travel 50 mm
            maximum axial offset 25 mm
            Vertikal stroke 80 mm
            total power requirement 1 kW
            weight of the machine ca. 200 kg
            dimensions of the machine ca. 60 x 100 x 220 cm
            Description :
            We quote a optical profile projector of type HAUSER 215K, machine no. 1635-164
            with 2-axe digital display. The tester is in good shape. This projector is
            equipped with cross table for radial travel of 25mm and axial travel of +/-
            25mm. The height adjustment is 80mm. There are 2 linear encoder from MSA type
            RSI. Both are connected to digital display of type R.S.F. type Z-502. The
            projector is complete running and can be inspected under power in our
            storage. Come for inspection to Giebelstadt, about 80min from Frankfurt airport.


            Attachment:
            The tester has an enlargement lense of factor 20x and 10x integrated.
            The unit has a hood with curtain.

            Actually we have some different projectors in warehouse. So come and you can
            select the suitable unit for your need.
          Datasheet
          Request / Contact

          Deburring Machine

          used  Deburring Machine EXTRUDE HONE ECM 4x450 A-2K


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00172 · Deburring Machine

          EXTRUDE HONE - ECM 4x450 A-2K - - 2006 -

          Technical details
          amperage - max. 4 x 450 A A︱range L-W-H ca. 4 x 4 x 3 m︱filter press ︱cooling unit
          We quote a ECM deburring machine EXTRUDE HONE in very good shape. The machine was used for deburring of SYNCHRONIZER. The machine can be inspected in our stock in Würzburg/Bavaria. Some datas: ECM-machine EXTRUDE HONE EH 23211/4x450 A • YOP 2006 • Machine number 2733 • complete unit for processing • including filter press • including air blasting system • including control cabin with 4 separate controlled modules + 1 new control module as spare part • including electrolyt bassin • including cooling unit for electrolyt • with tooling for SYNCHRONIZER • according attached pictures • with some accessoires from VW • with many drawings and manuals from VW for deburring SYNCHRONIZER •
            amperage - max. 4 x 450 A A
            range L-W-H ca. 4 x 4 x 3 m
            Description :
            We quote a ECM deburring machine EXTRUDE HONE in very good shape. The machine
            was used for deburring of SYNCHRONIZER. The machine can be inspected in our
            stock in Würzburg/Bavaria. Some datas: ECM-machine EXTRUDE HONE EH
            23211/4x450 A • YOP 2006 • Machine number 2733 • complete unit for processing •
            including filter press • including air blasting system • including control
            cabin with 4 separate controlled modules + 1 new control module as spare part •
            including electrolyt bassin • including cooling unit for
            electrolyt • with tooling for SYNCHRONIZER • according attached pictures • with
            some accessoires from VW • with many drawings and manuals from VW for deburring
            SYNCHRONIZER •

          Datasheet
          Request / Contact
          used  Deburring Machine VMB VMB ECM 400-30 E


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00267 · Deburring Machine

          VMB - VMB ECM 400-30 E - - 1999 -

          Technical details
          total power requirement 21 kW︱dimensions of the machine ca. 3,0x3,0x2,8 m︱diameter 400 mm︱workpiece length 400 mm︱work piece width 400 mm︱weight of the machine ca. 2,5 t︱current intensivity 300 A︱connected load frequency 400 VAC︱Required air-pressure 6 bar︱work stroke 400 mm︱daylight - vertical 655 mm︱
          We quote a ECM-deburring machine of type VMB ECM 400-30 E with 1 station and all neccessary attachment. We deliver: ECM-machine from 1999 in running condition with - machine number 356 - filter press with 15bar - control cabin in machine body with control SIEMENS OP5 - electrolyth basin integrated in machine body - separate cooling unit KÄLTE-MUSCHLER type MKK 020, volume 8,3m³/h - washing station of brand VORNDRAN Metallbau - floor pin - manual and electric plan Come for inspection now into our stock in Bavaria/Germany at ZÜFLE GMBH, LEVI-STRAUS-STRASSE 121, GERMANY-97232 GIEBELSTADT
            total power requirement 21 kW
            dimensions of the machine ca. 3,0x3,0x2,8 m
            diameter 400 mm
            workpiece length 400 mm
            work piece width 400 mm
            weight of the machine ca. 2,5 t
            current intensivity 300 A
            connected load frequency 400 VAC
            Required air-pressure 6 bar
            work stroke 400 mm
            daylight - vertical 655 mm
            Description :
            We quote a ECM-deburring machine of type VMB ECM 400-30 E with 1 station and
            all neccessary attachment. We deliver: ECM-machine from 1999 in running
            condition with
            - machine number 356
            - filter press with 15bar
            - control cabin in machine body with control SIEMENS OP5
            - electrolyth basin integrated in machine body
            - separate cooling unit KÄLTE-MUSCHLER type MKK 020, volume 8,3m³/h
            - washing station of brand VORNDRAN Metallbau
            - floor pin
            - manual and electric plan

            Come for inspection now into our stock in Bavaria/Germany at ZÜFLE GMBH,
            LEVI-STRAUS-STRASSE 121, GERMANY-97232 GIEBELSTADT
          12.700 €
          Datasheet
          Request / Contact
          used  Deburring Machine VMB VMB ECM 1000-24-2K


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00311 · Deburring Machine

          VMB - VMB ECM 1000-24-2K - - 1992 -

          Technical details
          total power requirement 100 kW︱dimensions of the machine ca. 6x6x2,3 m︱diameter 400 mm︱workpiece length 400 mm︱work piece width 400 mm︱weight of the machine ca. 3,5 t︱current intensivity 1000 A︱connected load frequency 400 VAC︱Required air-pressure 6 bar︱work stroke 400 mm︱
          We offer a 2-station ECM deburring system of the type VMB ECM 1000-24-2K with all accessories. The machine is complete and can be viewed in our warehouse in Giebelstadt. Scope of delivery: • Year of manufacture 1992 • Machine number 235 • Fully functional • Machine with separate control cabinet • Electrolyte container in the machine floor • with floor pan • with complete documentation Further accessories: • Filter press NETZSCH size 14 15bar • with pump • with suction device • with cooling unit KÄLTE-MUTSCHLER MIK160 for 22m³ / h • with wash basin Come and visit our warehouse in Giebelstadt, south of Würzburg
            total power requirement 100 kW
            dimensions of the machine ca. 6x6x2,3 m
            diameter 400 mm
            workpiece length 400 mm
            work piece width 400 mm
            weight of the machine ca. 3,5 t
            current intensivity 1000 A
            connected load frequency 400 VAC
            Required air-pressure 6 bar
            work stroke 400 mm
            Description :
            We offer a 2-station ECM deburring system of the type VMB ECM 1000-24-2K
            with all accessories. The machine is complete and can be viewed in our
            warehouse in Giebelstadt.

            Scope of delivery:
            • Year of manufacture 1992
            • Machine number 235
            • Fully functional
            • Machine with separate control cabinet
            • Electrolyte container in the machine floor
            • with floor pan
            • with complete documentation


            Further accessories:

            • Filter press NETZSCH size 14 15bar
            • with pump
            • with suction device
            • with cooling unit KÄLTE-MUTSCHLER MIK160 for 22m³ / h
            • with wash basin

            Come and visit our warehouse in Giebelstadt, south of
            Würzburg
          Datasheet
          Request / Contact

          Measuring Machine

          used  Measuring Machine FRENCO URM-R HGA


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-00285 · Measuring Machine

          FRENCO - URM-R HGA - - 2007 - PC-Steuerung

          Technical details
          x-travel 750 mm︱y-travel 120 mm︱z-travel 0 mm︱Control PC-Steuerung ︱swing diameter 240 mm︱centre distance 750 mm︱total power requirement 2 kW︱weight of the machine ca. 500 kg︱dimensions of the machine ca. 1,5 x 1,0 x 2,0 m︱
          We quote an universal gear tester for shaft parts including spline testing of FRENCO. This tester from 2007 has the type URM-R HGA and is a horizontal tester with tailstock and automatic measuring cycle. There are 6 measuring heads adapted and can measure parameters like: - dimension over balls (min./max./average) - runout of gears according to centres - Excentricity - pitch deviations with correlation to excentricity The max. lenght of shaft is 750mm and max. diameter up to 240mm. There are used encoders of HEIDENHAIN and pneumatic by FESTO. Come and inspect this tester in excellent condition in our stock under power. We are about 80min. away from FRANKFURT AIRPORT.
            x-travel 750 mm
            y-travel 120 mm
            Control PC-Steuerung
            swing diameter 240 mm
            centre distance 750 mm
            total power requirement 2 kW
            weight of the machine ca. 500 kg
            dimensions of the machine ca. 1,5 x 1,0 x 2,0 m
            Description :
            We quote an universal gear tester for shaft parts including spline testing of
            FRENCO. This tester from 2007 has the type URM-R HGA and is a horizontal tester
            with tailstock and automatic measuring cycle. There are 6 measuring heads
            adapted and can measure parameters like:

            - dimension over balls (min./max./average)
            - runout of gears according to centres
            - Excentricity
            - pitch deviations with correlation to excentricity

            The max. lenght of shaft is 750mm and max. diameter up to 240mm.
            There are used encoders of HEIDENHAIN and pneumatic by FESTO.

            Come and inspect this tester in excellent condition in our stock under power.
            We are about 80min. away from FRANKFURT AIRPORT.
          Datasheet
          Request / Contact

          Clamping Chuck

          used  Clamping Chuck RÖHM KFD-HS 315/3 Id. 427257-00205


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-10102 · Clamping Chuck

          RÖHM - KFD-HS 315/3 Id. 427257-00205 - - 2000 -

          Technical details
          diameter 315 mm︱weight of the machine ca. 60 kg︱Max. Speed RPM 4200 rpm︱F max. 8000 daN︱Sigma S max.
          Chuck of brand: RÖHM / GERMANY Type: KFD-HS 315/3 Id. 427257-00205 Spezifikation: Fmax. 8000 daN n max. 4200 U/min
            diameter 315 mm
            weight of the machine ca. 60 kg
            Max. Speed RPM 4200 rpm
            F max. 8000 daN
            Description :
            Chuck of brand: RÖHM / GERMANY Type: KFD-HS 315/3 Id. 427257-00205 Spezifikation: Fmax. 8000 daN n max. 4200 U/min
          Datasheet
          Request / Contact
          used  Clamping Chuck RÖHM KFD-HS 315/3 Id. 427257-N0313


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-10103 · Clamping Chuck

          RÖHM - KFD-HS 315/3 Id. 427257-N0313 - - 2000 -

          Technical details
          diameter 315 mm︱weight of the machine ca. 60 kg︱Max. Speed RPM 4200 rpm︱F max. 8000 daN︱Sigma S max.
          Chuck of brand: RÖHM / GERMANY Type: KFD-HS 315/3 Id. 427257-N0313 Spezifikation: Fmax. 8000 daN n max. 4200 U/min
            diameter 315 mm
            weight of the machine ca. 60 kg
            Max. Speed RPM 4200 rpm
            F max. 8000 daN
            Description :
            Chuck of brand: RÖHM / GERMANY Type: KFD-HS 315/3 Id. 427257-N0313 Spezifikation: Fmax. 8000 daN n max. 4200 U/min
          Datasheet
          Request / Contact
          used  Clamping Chuck RÖHM OVV-417526/506-23500


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-10100 · Clamping Chuck

          RÖHM - OVV-417526/506-23500 - - 2000 -

          Technical details
          diameter 315 mm︱weight of the machine ca. 60 kg︱F max. 3000 daN︱Max. Speed RPM ︱Sigma S max.
          Chuck of brand: RÖHM / GERMANY Type: 0VV 417526/50623500 Spezification: Fmax = 3000DAN
            diameter 315 mm
            weight of the machine ca. 60 kg
            F max. 3000 daN
            Description :
            Chuck of brand: RÖHM / GERMANY Type: 0VV 417526/50623500 Spezification: Fmax = 3000DAN
          Datasheet
          Request / Contact
          used  Clamping Chuck RÖHM OVV-417526/506-23500


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-10105 · Clamping Chuck

          RÖHM - OVV-417526/506-23500 - - 2000 -

          Technical details
          diameter 315 mm︱weight of the machine ca. 60 kg︱F max. 3000 daN︱Max. Speed RPM ︱Sigma S max.
          Chuck of brand: RÖHM / GERMANY Type: 0VV 417526/50623500 Spezification: Fmax = 3000DAN
            diameter 315 mm
            weight of the machine ca. 60 kg
            F max. 3000 daN
            Description :
            Chuck of brand: RÖHM / GERMANY Type: 0VV 417526/50623500 Spezification: Fmax = 3000DAN
          Datasheet
          Request / Contact
          used  Clamping Chuck RÖHM 1025592


          • Zuefle GmbH
          • Levi-Strauss-Str. 121
          • 97232 Giebelstadt
          • Deutschland

          • +49 (0)9334-978608-0
            +49 (0)9334-978608-2
          • info@zuefle.com
            www.zuefle.com
          #1139-10101 · Clamping Chuck

          RÖHM - 1025592 - - 2000 -

          Technical details
          diameter 270 mm︱weight of the machine ca. 60 kg︱Max. Speed RPM 3000 rpm︱F max. 3000 daN︱Sigma S max.
          Chuck of brand: RÖHM / GERMANY Type: 1025592 Spezification: Fmax = 3000daN nmax = 3000 rpm
            diameter 270 mm
            weight of the machine ca. 60 kg
            Max. Speed RPM 3000 rpm
            F max. 3000 daN
            Description :
            Chuck of brand: RÖHM / GERMANY Type: 1025592 Spezification: Fmax = 3000daN nmax = 3000 rpm
          Datasheet
          Request / Contact
          •
          •
          • 1
          • 2
          •
          •

            Trader Profile:   Zuefle GmbH

          Contact Trader



            Zuefle GmbH
           Levi-Strauss-Str. 121
            97232 Giebelstadt
            Deutschland
            +49 (0)9334-978608-0">+49 (0)9334-978608-0
            +49 (0)9334-978608-2
            info@zuefle.com
            www.zuefle.com

          Profile of Trader

          Since 1995 we are mainly active in the domain of gear technique. As a representative for manufacturers of gear producing machines, gear testing machines and tooling, we have received intensive knowledge in all technologies and part dimensions.

          Interested in customer specifications, we will search for the most economic solutions for producing gears. We like the unusual, the innovative and the vision.

          Today the ZÜFLE GmbH is trading of modernized and second hand gear machines. Additional we supply also machine tools in good condition. On our shop you can find also much tooling.

          We invite you to inspect machines and tooling in our stock in Würzburg, which is about 1h away from Frankfurt airport.

          In this homepage you can find actual quotes, technical datas and pictures of all machine tools

          Contact us for questions by email info@zuefle.com or by tel. +49-9334-9786080.

          Please see for yourself, that beside best machines and tools, service is our most important product.

          Dipl.-Ing. Dietmar Züfle


          Hallen

          Office & Warehouse
          Züfle GmbH
          Levi-Strauss-Str. 121
          D-97232 Giebelstadt

           +49 (0) 9334-978608-0
           +49 (0) 9334-978608-2

           info@zuefle.com




          Zuefle GmbH   97232 Giebelstadt Levi-Strauss-Str. 121 Deutschland
          Zuefle GmbH

          Levi-Strauss-Str. 121



          Contact Trader


            Zuefle GmbH
           Levi-Strauss-Str. 121
            97232 Giebelstadt
            Deutschland
            +49 (0)9334-978608-0
            +49 (0)9334-978608-2
            info@zuefle.com
            www.zuefle.com
            Contact person:






          Machine category


          Bandsäge - Vertikal · Container · Entgratmaschine · Ersatzteile · Geräuschprüfmaschine · Hochfrequenzspindel · Holzbearbeitungszentrum · Hydraulikaggregat · Kopierdrehmaschine · Kühlmittelanlage · Messmaschine · Messsystem · Motor · Profilprojektor · Radialbohrmaschine - Universal · Rundschleifmaschine - Außen · Räummaschine - Innen - Vertikal · Schärfmaschine · Sondermaschine · Spannfutter · Superfinishmaschine · Wälzfräserschärfmaschine · Zahnrad-Abwälzfräsmaschine - horizontal ·
