          Metal Processing - Plate Shear - Hydraulic

          Machinelist: Plate Shear - Hydraulic


          Plate Shear - Hydraulic

          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic BLEMAS (Hera) TK 3006 C (Demo)


          • Plum & Partner Werkzeugmaschinen GmbH
          • Winkelstraße 32
          • 32257 Bünde
          • Deutschland

          • +49 05223 574444
            +49 5223188330
          • info@plum-maschinen.de
            www.plum-maschinen.de
          #1082-11697 · Plate Shear - Hydraulic

          BLEMAS (Hera) - TK 3006 C (Demo) - - ungebraucht/unused - Blemas Control

          Technical details
          sheet width 3050 mm︱plate thickness 6 mm︱distance between columns 3050 mm︱cutting angle 1 - 3 Grad︱no. of strokes bei 1° = 13 per Min.︱back stop - adjustable 1000 mm︱hydraulic motor 7,5 kW︱control Blemas Control ︱thickness at "Niro-steel" 3 mm︱weight of the machine ca. 5400 kg︱dimensions of the machine ca. 3,9 x 2,1 x 2 m︱Electric 380 Volt ︱Motorized back gauge ︱Foot pedal ︱Side stop ︱Shadow line lighting ︱cutting split adjustment ︱Cutting lenght bound
          Unused hydraulic guillotine (exhibition machine at special price) with steering Blemas CONTROL control for backgauge-, cutting angle-, cutting gap adjustment as well as number of pieces and self-diagnosis system (shows current machine condition in the display). Furthermore, 5 stop dimensions can be stored and stop retraction can be set. In Tableau 3, the type and thickness of material is entered using LED keys and the machine automatically changes the cutting angle and gap. Back gauge with rapid and creep speed and automatic changeover, energy saving. Machine dealer with own stock of 2500 m².
            sheet width 3050 mm
            plate thickness 6 mm
            distance between columns 3050 mm
            cutting angle 1 - 3 Grad
            no. of strokes bei 1° = 13 per Min.
            back stop - adjustable 1000 mm
            hydraulic motor 7,5 kW
            control Blemas Control
            thickness at "Niro-steel" 3 mm
            weight of the machine ca. 5400 kg
            dimensions of the machine ca. 3,9 x 2,1 x 2 m
            Description :
            Unused hydraulic guillotine (exhibition machine at special price) with steering
            Blemas CONTROL control for backgauge-, cutting angle-, cutting gap adjustment
            as well as number of pieces and self-diagnosis system (shows current machine
            condition in the display).
            Furthermore, 5 stop dimensions can be stored and stop retraction can be set. In
            Tableau 3, the type and thickness of material is entered using LED keys and the
            machine automatically changes the cutting angle and gap. Back gauge with rapid
            and creep speed and automatic changeover, energy saving.
            Machine dealer with own stock of 2500 m².
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic GUIFIL GHB-425


          • INTER-PLAST
          • 42-209 Czestochowa

          • +48 343 627 904
            +48 785 198 061
          • iweta@inter-plast.com.pl
            www.inter-plast.com.pl
          #1129-600 · Plate Shear - Hydraulic

          GUIFIL - GHB-425 - - unbekannt -

          Technical details
          sheet width mm︱plate thickness mm︱distance between columns mm︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic JOERG 4086 - 3050 x 6 mm


          • Heinz Sanders GmbH
          • Fresenburger Weg 4
          • 49779 Niederlangen
          • Deutschland

          • +49 (0) 5939 9406 40
            +49 (0) 5939 9406 50
          • maschinen@heinz-sanders.de
            www.heinz-sanders.de
          #1125-6940 · Plate Shear - Hydraulic

          JOERG - 4086 - 3050 x 6 mm - - unbekannt -

          Technical details
          sheet width 3050 mm︱plate thickness 6 mm︱distance between columns -- mm︱down holder 16 Stück︱total power requirement 11 kW︱weight of the machine ca. 5,2 t︱dimensions of the machine ca. 4,0 x 2,5 x 1,7 m︱
            sheet width 3050 mm
            plate thickness 6 mm
            distance between columns -- mm
            down holder 16 Stück
            total power requirement 11 kW
            weight of the machine ca. 5,2 t
            dimensions of the machine ca. 4,0 x 2,5 x 1,7 m
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic ERMAK HGS-A 3100-6


          • EKW Werkzeugmaschinen e.K.
          • Zeppelinstrasse 1
          • 74219 Möckmühl-Züttlingen
          • Deutschland

          • ++49(0)6298-92120
            ++49(0)6298-921212
          • info@ekw-machines.de
            www.ekw-machines.de
          #1012-6737 · Plate Shear - Hydraulic

          ERMAK - HGS-A 3100-6 - - NEU -

          Technical details
          sheet width 3100 mm︱plate thickness 6,0 mm︱distance between columns 3150 mm︱thickness at "Niro-steel" 4,0 mm︱cutting angle 1,2 °︱no. of strokes 20 Hub/min︱ 14 St.︱main drive 15 kW︱back stop - adjustable 1000 mm︱cutting gap adjustment 0,05 - 0,8 mm︱quantity of oil ~150 l︱total power requirement kW︱weight of the machine ca. 5,65 t︱dimensions of the machine ca. 3,9 x 2,4 x 1,64 m︱
          * CYBELEC CybTouch 6 program control with big, luminous and contrasty full-touchscreen, EasyCut for single cuts, easy and clear display wit big keys * back stop adjustment by ball screw spindles 1000 mm - controlled by CybTouch * side stop in front with scale, T-slot tilt cams for right angular cuts L cuts =1000 mm * 2 bearing arms in front 1000 mm * ball screws and side stop and bearing arms for easy moving of sheets * quick cutting gap adjustment * cutting length limit * cutting line illumination * tiltable finger protection * movable foot switch * SIEMENS electronic device * BOSCH/HOERBIGER hydraulic system * safety light barrier at back side * CE-conformity declaration * 12 month guarantee * oil fill (if desired): 500 Euro * locally instruction/ start-up (if desired): 850 Euro
            sheet width 3100 mm
            plate thickness 6,0 mm
            distance between columns 3150 mm
            thickness at "Niro-steel" 4,0 mm
            cutting angle 1,2 °
            no. of strokes 20 Hub/min
            14 St.
            main drive 15 kW
            back stop - adjustable 1000 mm
            cutting gap adjustment 0,05 - 0,8 mm
            quantity of oil ~150 l
            weight of the machine ca. 5,65 t
            dimensions of the machine ca. 3,9 x 2,4 x 1,64 m
            Description :
            * CYBELEC CybTouch 6 program control with big, luminous and contrasty
            full-touchscreen, EasyCut for single cuts, easy and clear display wit big keys
            * back stop adjustment by ball screw spindles 1000 mm - controlled by
            CybTouch
            * side stop in front with scale, T-slot tilt cams for right angular cuts
            L cuts =1000 mm
            * 2 bearing arms in front 1000 mm
            * ball screws and side stop and bearing arms for easy moving of sheets
            * quick cutting gap adjustment
            * cutting length limit
            * cutting line illumination
            * tiltable finger protection
            * movable foot switch
            * SIEMENS electronic device
            * BOSCH/HOERBIGER hydraulic system
            * safety light barrier at back side
            * CE-conformity declaration
            * 12 month guarantee
            * oil fill (if desired): 500 Euro
            * locally instruction/ start-up (if desired): 850 Euro
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic FARINA CFO 306


          • Bästlein
          • Augsburger Str. 56
          • 89312 Günzburg
          • Deutschland

          • +49 (0) 8221 93037-0
            +49 (0) 8221 93037-29
          • info@baestlein.com
            www.baestlein.com
          #1123-4010855 · Plate Shear - Hydraulic

          FARINA - CFO 306 - - NEU - DELEM DAC 360s

          Technical details
          sheet width 3100 mm︱plate thickness 6 mm︱Control DELEM DAC 360s ︱pressure 260 kN︱back stop - adjustable 750 mm︱throat 500 mm︱cutting angle 30' - 3 °︱no. of strokes 33-58 Hub/min︱engine output 11 kW︱weight of the machine ca. 8.700 kg︱
          Domestic equipments: - DELEM DAC 360 4.7" LCD screen for automatic control of:    - Cutting angle    - kerf    - Cutting length    - Programming the backgauge    - stroke counter - Protection of the front work area by light curtains - motor driven back gauge - Cutting length limit - Angle stop: 700 mm plus table - Support arms: 700 mm plus table - cut line lighting - Standard knife: R = 42 kg / mm² - Footswitch - Control key - Operating instructions and maintenance instructions - Machine with standard standard 2006/42 / CE and CE certificate
            sheet width 3100 mm
            plate thickness 6 mm
            Control DELEM DAC 360s
            pressure 260 kN
            back stop - adjustable 750 mm
            throat 500 mm
            cutting angle 30' - 3 °
            no. of strokes 33-58 Hub/min
            engine output 11 kW
            weight of the machine ca. 8.700 kg
            Description :
            Domestic equipments:
            - DELEM DAC 360 4.7" LCD screen for automatic control of:
               - Cutting angle
               - kerf
               - Cutting length
               - Programming the backgauge
               - stroke counter
            - Protection of the front work area by light curtains
            - motor driven back gauge
            - Cutting length limit
            - Angle stop: 700 mm plus table
            - Support arms: 700 mm plus table
            - cut line lighting
            - Standard knife: R = 42 kg / mm²
            - Footswitch
            - Control key
            - Operating instructions and maintenance instructions
            - Machine with standard standard 2006/42 / CE and CE certificate
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic ERMAK CNC HGD 3100x10


          • Bästlein
          • Augsburger Str. 56
          • 89312 Günzburg
          • Deutschland

          • +49 (0) 8221 93037-0
            +49 (0) 8221 93037-29
          • info@baestlein.com
            www.baestlein.com
          #1123-4010523 · Plate Shear - Hydraulic

          ERMAK - CNC HGD 3100x10 - - Neu -

          Technical details
          sheet width 3100 mm︱plate thickness 10 mm︱cutting angle 2 °︱down holder 14 Stück︱no. of strokes 13 Hub/min︱throat 350 mm︱oil volume 260 l︱total power requirement 22 kW︱weight of the machine ca. 10.550 kg︱dimensions of the machine ca. 4000x2250x2050 mm︱
          Domestic equipments: - Hydraulic swing cut sheet metal shears - Touch screen controller with digital display for backgauge - automatic kerf adjustment via the control - Backgauge control 1000 mm travel with recirculating ball screws - Vibration cutting machine with kerf adjustment - 2 support arms - 1 side stop - Photocell behind the machine - Cutting length limit - cut line lighting - Chrome steel knife - Ball rolls in the table - hinged finger guard with limit switch - Footswitch - CE mark / Declaration of Conformity - Bed instructions in German
            sheet width 3100 mm
            plate thickness 10 mm
            cutting angle 2 °
            down holder 14 Stück
            no. of strokes 13 Hub/min
            throat 350 mm
            oil volume 260 l
            total power requirement 22 kW
            weight of the machine ca. 10.550 kg
            dimensions of the machine ca. 4000x2250x2050 mm
            Description :
            Domestic equipments:
            - Hydraulic swing cut sheet metal shears
            - Touch screen controller with digital display for backgauge
            - automatic kerf adjustment via the control
            - Backgauge control 1000 mm travel with recirculating ball screws
            - Vibration cutting machine with kerf adjustment
            - 2 support arms
            - 1 side stop
            - Photocell behind the machine
            - Cutting length limit
            - cut line lighting
            - Chrome steel knife
            - Ball rolls in the table
            - hinged finger guard with limit switch
            - Footswitch
            - CE mark / Declaration of Conformity
            - Bed instructions in German
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic FARINA CFO 154


          • Bästlein
          • Augsburger Str. 56
          • 89312 Günzburg
          • Deutschland

          • +49 (0) 8221 93037-0
            +49 (0) 8221 93037-29
          • info@baestlein.com
            www.baestlein.com
          #1123-4010873 · Plate Shear - Hydraulic

          FARINA - CFO 154 - - NEU -

          Technical details
          sheet width 1600 mm︱plate thickness 4 mm︱column daylight 1700 mm︱pressure 200 kN︱back stop - adjustable 750 mm︱throat 500 mm︱cutting angle 30' - 3 °︱no. of strokes 35-60 Hub/min︱engine output 7,5 kW︱weight of the machine ca. 4.900 kg︱
          Standard Equipment: - Motor-driven back gauge with two speeds and recirculation ball screws. - Numeric control PRG 911 for the control of back gauge. - PRG 911 Working operations: - Manual mode - semi-automatic (when you enter the desired measure and push the start, the back gauge move to the programmed measure) - automatic (programming of different measures on a plate – storage up to 99 programs composed of 1-99 repetition). - stroke counter - automatic retraction of the back gauge as soon as the blank holder pistons have locked the plate. - manual blade distance adjustment with dimensional mechanical control. - Spherical balls in table for easy sheet movement - Hydraulic adjustable cutting angle with dimensional control display - cutting length potentiometer - side squaring arm L = 700 mm plus table - standard extension arms L = 700 mm plus table - cutting light & wire - standard blades for plate R=42 kg/mm2 - control foot pedal - service keys - instruction and maintenance manual - oil excluded - Machine according to standard 2006/42/CE and CE certificate
            sheet width 1600 mm
            plate thickness 4 mm
            column daylight 1700 mm
            pressure 200 kN
            back stop - adjustable 750 mm
            throat 500 mm
            cutting angle 30' - 3 °
            no. of strokes 35-60 Hub/min
            engine output 7,5 kW
            weight of the machine ca. 4.900 kg
            Description :
            Standard Equipment:
            - Motor-driven back gauge with two speeds and recirculation ball screws.
            - Numeric control PRG 911 for the control of back gauge.
            - PRG 911 Working operations:
            - Manual mode
            - semi-automatic (when you enter the desired measure and push the start,
            the back gauge move to the programmed measure)
            - automatic (programming of different measures on a plate – storage up to
            99 programs composed of 1-99 repetition).
            - stroke counter
            - automatic retraction of the back gauge as soon as the blank holder pistons
            have locked the plate.

            - manual blade distance adjustment with dimensional mechanical control.
            - Spherical balls in table for easy sheet movement
            - Hydraulic adjustable cutting angle with dimensional control display
            - cutting length potentiometer
            - side squaring arm L = 700 mm plus table
            - standard extension arms L = 700 mm plus table
            - cutting light & wire
            - standard blades for plate R=42 kg/mm2
            - control foot pedal
            - service keys
            - instruction and maintenance manual
            - oil excluded
            - Machine according to standard 2006/42/CE and CE certificate
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic ERMAK CNC HGS 3100x6


          • Bästlein
          • Augsburger Str. 56
          • 89312 Günzburg
          • Deutschland

          • +49 (0) 8221 93037-0
            +49 (0) 8221 93037-29
          • info@baestlein.com
            www.baestlein.com
          #1123-4010594 · Plate Shear - Hydraulic

          ERMAK - CNC HGS 3100x6 - - Neu - CYBELEC CybTouch

          Technical details
          sheet width 3100 mm︱plate thickness 6 mm︱voltage 380 V︱control CYBELEC CybTouch ︱down holder 14 Stück︱cutting angle 1,2 °︱total power requirement 11 kW︱weight of the machine ca. 5700 kg︱dimensions of the machine ca. 4000x2100x1640 mm︱
          Accessories / equipment: - CYBELEC Cybtouch touch screen controller - NC controller for backgauge, gap adjustment, number of pieces, cutting length - 1 side stop with scale, T-groove and tilting cam - 2 front support arms - cut line lighting - Cutting gap adjustment - Cutting length limit - Folding finger guard with limit switch - motorized back gauge 1.000 mm travel - Ball screws - Photocell behind the machine - Ball rolls in the table - SIEMENS electrical system - BOSCH / HOERBIGER hydraulic system - Footswitch - CE mark / Declaration of Conformity - Operating manual: Machine and control in German
            sheet width 3100 mm
            plate thickness 6 mm
            voltage 380 V
            control CYBELEC CybTouch
            down holder 14 Stück
            cutting angle 1,2 °
            total power requirement 11 kW
            weight of the machine ca. 5700 kg
            dimensions of the machine ca. 4000x2100x1640 mm
            Description :
            Accessories / equipment:
            - CYBELEC Cybtouch touch screen controller
            - NC controller for backgauge, gap adjustment, number of pieces,
            cutting length
            - 1 side stop with scale, T-groove and tilting cam
            - 2 front support arms
            - cut line lighting
            - Cutting gap adjustment
            - Cutting length limit
            - Folding finger guard with limit switch
            - motorized back gauge 1.000 mm travel
            - Ball screws
            - Photocell behind the machine
            - Ball rolls in the table
            - SIEMENS electrical system
            - BOSCH / HOERBIGER hydraulic system
            - Footswitch
            - CE mark / Declaration of Conformity
            - Operating manual: Machine and control in German
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic ERMAK CNC HGD 3100x13


          • Bästlein
          • Augsburger Str. 56
          • 89312 Günzburg
          • Deutschland

          • +49 (0) 8221 93037-0
            +49 (0) 8221 93037-29
          • info@baestlein.com
            www.baestlein.com
          #1123-4010788 · Plate Shear - Hydraulic

          ERMAK - CNC HGD 3100x13 - - Neu - CYBELEC CybTouch

          Technical details
          sheet width 3100 mm︱plate thickness 13 mm︱thickness at "Niro-steel" 8 mm︱control CYBELEC CybTouch ︱down holder 14 Stück︱cutting angle 2,0° °︱total power requirement 22 kW︱voltage 380 V︱no. of strokes 11 Hub/min︱weight of the machine ca. 12.100 kg︱dimensions of the machine ca. 4000x2240x2235 mm︱
          Accessories / equipment: - CYBELEC-CybTouch control panel with digital display for backgauge - hydr. Cutting gap adjustment via control - 1 side stop - 4 front lifting arms - cut line lighting - Cutting gap adjustment - Cutting length limit - Ball rolls in the table - motorized back gauge 1.000 mm travel with recirculating ball screws,    automatically start at the end of the stop - Shear knives for stainless steel cuts as standard - Photocell behind the machine - SIEMENS electrical system - BOSCH / HOERBIGER hydraulic system - Footswitch - Operating instructions in German
            sheet width 3100 mm
            plate thickness 13 mm
            thickness at "Niro-steel" 8 mm
            control CYBELEC CybTouch
            down holder 14 Stück
            cutting angle 2,0° °
            total power requirement 22 kW
            voltage 380 V
            no. of strokes 11 Hub/min
            weight of the machine ca. 12.100 kg
            dimensions of the machine ca. 4000x2240x2235 mm
            Description :
            Accessories / equipment:
            - CYBELEC-CybTouch control panel with digital display for backgauge
            - hydr. Cutting gap adjustment via control
            - 1 side stop
            - 4 front lifting arms
            - cut line lighting
            - Cutting gap adjustment
            - Cutting length limit
            - Ball rolls in the table
            - motorized back gauge 1.000 mm travel with recirculating ball screws,
               automatically start at the end of the stop
            - Shear knives for stainless steel cuts as standard
            - Photocell behind the machine
            - SIEMENS electrical system
            - BOSCH / HOERBIGER hydraulic system
            - Footswitch
            - Operating instructions in German
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic FARINA CFO 313


          • Bästlein
          • Augsburger Str. 56
          • 89312 Günzburg
          • Deutschland

          • +49 (0) 8221 93037-0
            +49 (0) 8221 93037-29
          • info@baestlein.com
            www.baestlein.com
          #1123-4010852 · Plate Shear - Hydraulic

          FARINA - CFO 313 - - NEU - DELEM DAC 360

          Technical details
          sheet width 3100 mm︱plate thickness 13 mm︱pressure 560 kN︱back stop - adjustable 1020 mm︱throat 500 mm︱cutting angle 30' - 3 °︱no. of strokes 22-40 Hub/min︱engine output 22 kW︱control DELEM DAC 360 ︱dimensions 3800x2200x2400 mm︱weight of the machine ca. 14000 kg︱
          Domestic equipments: - motor driven back gauge - Via the control Delem DAC 360 4.7 "LCD adjustable:   - Cutting angle   - kerf   - Cutting length   - backgauge   - number of strokes - Ball rollers in the support table for easy handling - hydraulically adjustable cutting angle with dimension display - Cutting length limit - Angle stop: 700mm plus table - Support arms: 700mm plus table - cut line lighting - Standard knife: R = 42 kg / mm² - Footswitch - Control key - Operating and maintenance instructions - Machine with standard standard 2006/42 / CE and CE certificate
            sheet width 3100 mm
            plate thickness 13 mm
            pressure 560 kN
            back stop - adjustable 1020 mm
            throat 500 mm
            cutting angle 30' - 3 °
            no. of strokes 22-40 Hub/min
            engine output 22 kW
            control DELEM DAC 360
            dimensions 3800x2200x2400 mm
            weight of the machine ca. 14000 kg
            Description :
            Domestic equipments:
            - motor driven back gauge
            - Via the control Delem DAC 360 4.7 "LCD adjustable:
              - Cutting angle
              - kerf
              - Cutting length
              - backgauge
              - number of strokes
            - Ball rollers in the support table for easy handling
            - hydraulically adjustable cutting angle with dimension display
            - Cutting length limit
            - Angle stop: 700mm plus table
            - Support arms: 700mm plus table
            - cut line lighting
            - Standard knife: R = 42 kg / mm²
            - Footswitch
            - Control key
            - Operating and maintenance instructions
            - Machine with standard standard 2006/42 / CE and CE certificate
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic FARINA CFO 206


          • Bästlein
          • Augsburger Str. 56
          • 89312 Günzburg
          • Deutschland

          • +49 (0) 8221 93037-0
            +49 (0) 8221 93037-29
          • info@baestlein.com
            www.baestlein.com
          #1123-4010861 · Plate Shear - Hydraulic

          FARINA - CFO 206 - - NEU -

          Technical details
          sheet width 2100 mm︱plate thickness 6 mm︱column daylight 2200 mm︱pressure 260 kN︱back stop - adjustable 750 mm︱throat 500 mm︱cutting angle 30' - 3 °︱no. of strokes 33-58 Hub/min︱engine output 11 kW︱dimensions of the machine ca. 2750x1950x1912 (2752) mm︱weight of the machine ca. 5.700 kg︱
          - Motor-driven back gauge with servo brushless motor and recirculation ball screws. - Electronic programmer with microprocessors Delem model DAC 360 4.7” LCD screen for automatic control of: - cutting angle - blade gap - cutting length - programming of back gauge - stroke counter - Spherical balls in table for easy sheet movement - Hydraulic adjustable cutting angle with dimensional control display - cutting length potentiometer - side squaring arm L. 2000mm with retractable stop and millimetre scale in stainless steel - standard extension arms L. 2000mm - cutting light & wire - standard blades for plate R=42 kg/mm2 - control foot pedal - Centralised automatic lubrication system - Management of the oil temperature : Air-oil heating exchanger with forced ventilation - Electric cabinet conditioner : For cooling the electric cabinet - service keys - instruction and maintenance manual - oil excluded - Machine according to standard 2006/42/CE and CE certificate
            sheet width 2100 mm
            plate thickness 6 mm
            column daylight 2200 mm
            pressure 260 kN
            back stop - adjustable 750 mm
            throat 500 mm
            cutting angle 30' - 3 °
            no. of strokes 33-58 Hub/min
            engine output 11 kW
            dimensions of the machine ca. 2750x1950x1912 (2752) mm
            weight of the machine ca. 5.700 kg
            Description :
            - Motor-driven back gauge with servo brushless motor and recirculation ball screws.
            - Electronic programmer with microprocessors Delem model DAC 360 4.7” LCD screen for automatic control of:
            - cutting angle
            - blade gap
            - cutting length
            - programming of back gauge
            - stroke counter
            - Spherical balls in table for easy sheet movement
            - Hydraulic adjustable cutting angle with dimensional control display
            - cutting length potentiometer
            - side squaring arm L. 2000mm with retractable stop and millimetre scale in stainless steel
            - standard extension arms L. 2000mm
            - cutting light & wire
            - standard blades for plate R=42 kg/mm2
            - control foot pedal
            - Centralised automatic lubrication system
            - Management of the oil temperature : Air-oil heating exchanger with forced ventilation
            - Electric cabinet conditioner : For cooling the electric cabinet
            - service keys
            - instruction and maintenance manual
            - oil excluded
            - Machine according to standard 2006/42/CE and CE certificate

          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic FARINA CFO 310


          • Bästlein
          • Augsburger Str. 56
          • 89312 Günzburg
          • Deutschland

          • +49 (0) 8221 93037-0
            +49 (0) 8221 93037-29
          • info@baestlein.com
            www.baestlein.com
          #1123-4010863 · Plate Shear - Hydraulic

          FARINA - CFO 310 - - NEU - DELEM DAC 360

          Technical details
          sheet width 3100 mm︱plate thickness 10 mm︱pressure 480 kN︱back stop - adjustable 1020 mm︱throat 500 mm︱cutting angle 30' - 3 °︱no. of strokes 25/48 Hub/min︱engine output 22,5 kW︱control DELEM DAC 360 ︱dimensions 3800x2200x2200 mm︱weight of the machine ca. 13500 kg︱
          Domestic equipments: - motor driven back gauge - pneumatic sheet holding device - Via the control Delem DAC 360 4.7 "LCD adjustable:   - Cutting angle   - kerf   - Cutting length   - backgauge   - number of strokes - Ball rollers in the support table for easy handling - hydraulically adjustable cutting angle with dimension display - Cutting length limit - Angle stop: 700 mm plus table - Support arms: 700 mm plus table - cut line lighting - Standard knife: R = 42 kg / mm² - Footswitch - Control key - Operating and maintenance instructions - Machine with standard standard 2006/42 / CE and CE certificate
            sheet width 3100 mm
            plate thickness 10 mm
            pressure 480 kN
            back stop - adjustable 1020 mm
            throat 500 mm
            cutting angle 30' - 3 °
            no. of strokes 25/48 Hub/min
            engine output 22,5 kW
            control DELEM DAC 360
            dimensions 3800x2200x2200 mm
            weight of the machine ca. 13500 kg
            Description :
            Domestic equipments:
            - motor driven back gauge
            - pneumatic sheet holding device
            - Via the control Delem DAC 360 4.7 "LCD adjustable:
              - Cutting angle
              - kerf
              - Cutting length
              - backgauge
              - number of strokes
            - Ball rollers in the support table for easy handling
            - hydraulically adjustable cutting angle with dimension display
            - Cutting length limit
            - Angle stop: 700 mm plus table
            - Support arms: 700 mm plus table
            - cut line lighting
            - Standard knife: R = 42 kg / mm²
            - Footswitch
            - Control key
            - Operating and maintenance instructions
            - Machine with standard standard 2006/42 / CE and CE certificate
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic STEINER HTS 30-16 RA


          • Hans Klein Werkzeugmaschinenhandel GmbH
          • Im Mühlgut 2-4
          • 77815 Bühl
          • Deutschland

          • 0049 (0) 7223 9617-0
            0049 (0) 7223 58512
          • info@klein-werkzeugmaschinen.de
            www.klein-werkzeugmaschinen.de
          #1052-01256 · Plate Shear - Hydraulic

          STEINER - HTS 30-16 RA - - ca. 1978 -

          Technical details
          sheet width 3050 mm︱plate thickness 16 mm︱distance between columns - mm︱back stop - adjustable 1000 mm︱total power requirement kW︱weight of the machine ca. 15 t︱dimensions 4,1 x 1,8 x 2,88 m︱
          Acc.: electr. back gauge with DRO, table extensions
            sheet width 3050 mm
            plate thickness 16 mm
            distance between columns - mm
            back stop - adjustable 1000 mm
            weight of the machine ca. 15 t
            dimensions 4,1 x 1,8 x 2,88 m
            Description :
            Acc.: electr. back gauge with DRO, table extensions
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic DURMA SBT 3010


          • Frech GmbH
          • Werderstr. 82
          • 74889 Sinsheim
          • Deutschland

          • 0049-7261-1011
            0049-7261-63966
          • info@frech-maschinen.de
            www.frech-maschinen.de
          #1073-93716 · Plate Shear - Hydraulic

          DURMA - SBT 3010 - - 2018 -

          Technical details
          sheet width 3100 mm︱plate thickness 10,00 mm︱distance between columns mm︱cutting angle 1,5 °︱throat 50 mm︱stroke 110 mm︱stroke per min. 13 ︱back gauge - adjustable by motor 1000 ︱total power requirement kW︱weight of the machine ca. 9,1 t︱dimensions of the machine ca. 4,20 x 3,60 x 2,10 m︱
          Equipment: - NC pre-selection control D-Touch 7 with touch screen for back gauge, cutting length, number of pieces - Central cutting gap adjustment mechanically - Motorized backgauge up to 1,000 mm on ball screws, can be folded up - Clear control panel mounted on swivel arm - foot switch - cutting line lighting
            sheet width 3100 mm
            plate thickness 10,00 mm
            cutting angle 1,5 °
            throat 50 mm
            stroke 110 mm
            stroke per min. 13
            back gauge - adjustable by motor 1000
            weight of the machine ca. 9,1 t
            dimensions of the machine ca. 4,20 x 3,60 x 2,10 m
            Description :
            Equipment:
            - NC pre-selection control D-Touch 7 with touch screen for back gauge, cutting
            length, number of pieces
            - Central cutting gap adjustment mechanically
            - Motorized backgauge up to 1,000 mm on ball screws, can be folded up
            - Clear control panel mounted on swivel arm
            - foot switch
            - cutting line lighting
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic QC 12X3200


          • Frech GmbH
          • Werderstr. 82
          • 74889 Sinsheim
          • Deutschland

          • 0049-7261-1011
            0049-7261-63966
          • info@frech-maschinen.de
            www.frech-maschinen.de
          #1073-93685 · Plate Shear - Hydraulic

          QC - 12X3200 - - 2013 -

          Technical details
          sheet width 3200 mm︱plate thickness 12,00 mm︱distance between columns mm︱total power requirement 18,5 kW︱weight of the machine ca. 10,0 t︱dimensions of the machine ca. 4,00 x 2,40 x1,80 m︱
          Equipment: - electr. back gauge - Cut gap adjustment - ELGO P40 control - angle stop - support arms
            sheet width 3200 mm
            plate thickness 12,00 mm
            total power requirement 18,5 kW
            weight of the machine ca. 10,0 t
            dimensions of the machine ca. 4,00 x 2,40 x1,80 m
            Description :
            Equipment:
            - electr. back gauge
            - Cut gap adjustment
            - ELGO P40 control
            - angle stop
            - support arms
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic ERMAK CNC HGD 3100-13


          • Frech GmbH
          • Werderstr. 82
          • 74889 Sinsheim
          • Deutschland

          • 0049-7261-1011
            0049-7261-63966
          • info@frech-maschinen.de
            www.frech-maschinen.de
          #1073-93715 · Plate Shear - Hydraulic

          ERMAK - CNC HGD 3100-13 - - 2013 -

          Technical details
          sheet width 3100 mm︱plate thickness 13,00 mm︱thickness at "Niro-steel" 8,00 mm︱down holder 14 Stück︱no. of strokes 11 Hub/min︱oil volume 310 ltr.︱cutting angle 2,0 °︱throat 350 mm︱table height 900 mm︱total power requirement 22,0 kW︱weight of the machine ca. 11.210 kg︱range L-W-H ca. 4100 x 2300 x 2235 mm︱
          * heavy vibration cut sheet metal shears * New price: approx.42,000 euros Furnishing: - CNC CYBELEC CybTouch control - Touchscreen control panel - electr. Back gauge with 1,000 mm travel - with ball screws, autom. Start up at the end of the stroke - Accuracy - travel 0.1 mm - Electr./hydr.- cutting gap adjustment via CNC control - cutting line lighting - electr. Cutting length limitation - Ball rollers in the support table - Scissors knife for stainless steel cuts - Safety device / light barrier behind the machine - SIEMENS electrical system - BOSCH / HOERBIGER hydraulic components - foot switch - Instructions in German - CE declaration * Special accessories included: - pneumatic sheet holding device - 1x extended side stop 2,000 mm, with scale - 1x extended arm 2,000 mm, with scale - front / open light barrier
            sheet width 3100 mm
            plate thickness 13,00 mm
            thickness at "Niro-steel" 8,00 mm
            down holder 14 Stück
            no. of strokes 11 Hub/min
            oil volume 310 ltr.
            cutting angle 2,0 °
            throat 350 mm
            table height 900 mm
            total power requirement 22,0 kW
            weight of the machine ca. 11.210 kg
            range L-W-H ca. 4100 x 2300 x 2235 mm
            Description :
            * heavy vibration cut sheet metal shears
            * New price: approx.42,000 euros

            Furnishing:
            - CNC CYBELEC CybTouch control
            - Touchscreen control panel
            - electr. Back gauge with 1,000 mm travel
            - with ball screws, autom. Start up at the end of the stroke
            - Accuracy - travel 0.1 mm
            - Electr./hydr.- cutting gap adjustment via CNC control
            - cutting line lighting
            - electr. Cutting length limitation
            - Ball rollers in the support table
            - Scissors knife for stainless steel cuts
            - Safety device / light barrier behind the machine
            - SIEMENS electrical system
            - BOSCH / HOERBIGER hydraulic components
            - foot switch
            - Instructions in German
            - CE declaration

            * Special accessories included:
            - pneumatic sheet holding device
            - 1x extended side stop 2,000 mm, with scale
            - 1x extended arm 2,000 mm, with scale
            - front / open light barrier
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic ERMAK CNC HGD 3100-13


          • A + B Werkzeuge Maschinen Handels GmbH
          • Rottweg 17
          • 48683 Ahaus
          • Deutschland

          • (0049)-2561-9384-31
            (0049)-2561-9384-36
          • info@ab-maschinen.de
            www.ab-maschinen.de
          #1008-9321177 · Plate Shear - Hydraulic

          ERMAK - CNC HGD 3100-13 - - 2013 -

          Technical details
          sheet width 3100 mm︱plate thickness 13,0 mm︱thickness at "Niro-steel" 8,0 mm︱down holder 14 Stück︱no. of strokes 11 Hub/min︱oil volume 310 ltr.︱cutting angle 2,0 °︱throat 350 mm︱table height 900 mm︱total power requirement 22,0 kW︱weight of the machine ca. 11.210 kg︱range L-W-H ca. 4100 x 2300 x 2235 mm︱
            sheet width 3100 mm
            plate thickness 13,0 mm
            thickness at "Niro-steel" 8,0 mm
            down holder 14 Stück
            no. of strokes 11 Hub/min
            oil volume 310 ltr.
            cutting angle 2,0 °
            throat 350 mm
            table height 900 mm
            total power requirement 22,0 kW
            weight of the machine ca. 11.210 kg
            range L-W-H ca. 4100 x 2300 x 2235 mm
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic ERMAKSAN HGS 3100X6


          • ProdEq Trading
          • Reckholder 1
          • 9527 Niederhelfenschwil
          • Schweiz

          • (0041)71 - 948 7060
            (0041)71 - 948 7069
          • info@prodeq.ch
            www.prodeq.ch
          #1045-40694 · Plate Shear - Hydraulic

          ERMAKSAN - HGS 3100X6 - - 2013 - ERMAKSAN TOUCH SCREEN

          Technical details
          sheet width mm︱plate thickness 6 mm︱distance between columns mm︱-------------------------------------------------- ︱TECHNICAL SPECIFICATION ︱- Working length 3100 mm︱- plate thickness (max.) 6 mm︱- stroke rate 20 /min︱- Back gauge adjustable from 1000 mm︱ELECTRICAL SPECIFICATIONS ︱- total power consumption 11 kW︱DIMENSIONS / WEIGHTS ︱- space requirements -left/right- 4000 mm︱- space requirements -front/back- 3010 mm︱- total height 1640 mm︱- total weight approx. 5700 kg︱
            plate thickness 6 mm
            - Working length 3100 mm
            - plate thickness (max.) 6 mm
            - stroke rate 20 /min
            - Back gauge adjustable . 1000 mm
            - total power consumption 11 kW
            - space requirements -left/right. 4000 mm
            - space requirements -front/back. 3010 mm
            - total height 1640 mm
            - total weight approx. 5700 kg
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic ERMAKSAN HGS 3100X6


          • MS Maschinenhandel GmbH
          • Unterdorf 34
          • 6532 Ladis
          • Österreich

          • +43 (0) 5472 219 07
            +43 (0) 5472 219 07 22
          • info@ms-maschinen.at
            www.ms-maschinen.at
          #2034-40694 · Plate Shear - Hydraulic

          ERMAKSAN - HGS 3100X6 - - 2013 - ERMAKSAN TOUCH SCREEN

          Technical details
          sheet width mm︱plate thickness 6 mm︱distance between columns mm︱-------------------------------------------------- ︱TECHNICAL SPECIFICATION ︱- Working length 3100 mm︱- plate thickness (max.) 6 mm︱- stroke rate 20 /min︱- Back gauge adjustable from 1000 mm︱ELECTRICAL SPECIFICATIONS ︱- total power consumption 11 kW︱DIMENSIONS / WEIGHTS ︱- space requirements -left/right- 4000 mm︱- space requirements -front/back- 3010 mm︱- total height 1640 mm︱- total weight approx. 5700 kg︱
            plate thickness 6 mm
            - Working length 3100 mm
            - plate thickness (max.) 6 mm
            - stroke rate 20 /min
            - Back gauge adjustable . 1000 mm
            - total power consumption 11 kW
            - space requirements -left/right. 4000 mm
            - space requirements -front/back. 3010 mm
            - total height 1640 mm
            - total weight approx. 5700 kg
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic KAMI QH11D 2000x3,5


          • Frech GmbH
          • Werderstr. 82
          • 74889 Sinsheim
          • Deutschland

          • 0049-7261-1011
            0049-7261-63966
          • info@frech-maschinen.de
            www.frech-maschinen.de
          #1073-93733 · Plate Shear - Hydraulic

          KAMI - QH11D 2000x3,5 - - 2012 -

          Technical details
          sheet width 2000 mm︱plate thickness 3,50 mm︱distance between columns mm︱total power requirement 7,50 kW︱weight of the machine ca. 1,90 t︱dimensions of the machine ca. B2,65 x 2,20 x 1,20 m︱
          Furnishing: • Motorized back gauge 20 - 1000 mm with digital display • Angle stop • Support arms • Rear safety grille • Operation manual
            sheet width 2000 mm
            plate thickness 3,50 mm
            total power requirement 7,50 kW
            weight of the machine ca. 1,90 t
            dimensions of the machine ca. B2,65 x 2,20 x 1,20 m
            Description :
            Furnishing:
            • Motorized back gauge 20 - 1000 mm with digital display
            • Angle stop
            • Support arms
            • Rear safety grille
            • Operation manual
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic BOSCHERT G - CUT - CNC


          • ERICH MIETH Maschinenhandel
          • Odenwaldstraße 63
          • 63322 Rödermark
          • Deutschland

          • +49 (0) 6074 908 77
            +49 (0) 6074 909 10
          • info@mieth-maschinen.de
            www.mieth-maschinen.de
          #2051-19416 · Plate Shear - Hydraulic

          BOSCHERT - G - CUT - CNC - - 2012 -

          Technical details
          sheet width - ︱plate thickness - ︱distance between columns -
            sheet width -
            plate thickness -
            distance between columns -
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic DURMA VS 3010


          • ProdEq Trading
          • Reckholder 1
          • 9527 Niederhelfenschwil
          • Schweiz

          • (0041)71 - 948 7060
            (0041)71 - 948 7069
          • info@prodeq.ch
            www.prodeq.ch
          #1045-41160 · Plate Shear - Hydraulic

          DURMA - VS 3010 - - 2010 -

          Technical details
          sheet width mm︱plate thickness 10 mm︱distance between columns mm︱-------------------------------------------------- ︱TECHNICAL SPECIFICATION ︱- Working length 3080 mm︱- plate thickness (max.) 10 mm︱- stroke rate 20 /min︱- Back gauge adjustable to 1000 mm︱ELECTRICAL SPECIFICATIONS ︱- total power consumption 22 kW︱DIMENSIONS / WEIGHTS ︱- space requirements -left/right- 3800 mm︱- space requirements -front/back- 2050 mm︱- total height 2150 mm︱- total weight approx. 9300 kg︱
            plate thickness 10 mm
            - Working length 3080 mm
            - plate thickness (max.) 10 mm
            - stroke rate 20 /min
            - Back gauge adjustable . 1000 mm
            - total power consumption 22 kW
            - space requirements -left/right. 3800 mm
            - space requirements -front/back. 2050 mm
            - total height 2150 mm
            - total weight approx. 9300 kg
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic DURMA VS 3010


          • MS Maschinenhandel GmbH
          • Unterdorf 34
          • 6532 Ladis
          • Österreich

          • +43 (0) 5472 219 07
            +43 (0) 5472 219 07 22
          • info@ms-maschinen.at
            www.ms-maschinen.at
          #2034-41160 · Plate Shear - Hydraulic

          DURMA - VS 3010 - - 2010 -

          Technical details
          sheet width mm︱plate thickness 10 mm︱distance between columns mm︱-------------------------------------------------- ︱TECHNICAL SPECIFICATION ︱- Working length 3080 mm︱- plate thickness (max.) 10 mm︱- stroke rate 20 /min︱- Back gauge adjustable to 1000 mm︱ELECTRICAL SPECIFICATIONS ︱- total power consumption 22 kW︱DIMENSIONS / WEIGHTS ︱- space requirements -left/right- 3800 mm︱- space requirements -front/back- 2050 mm︱- total height 2150 mm︱- total weight approx. 9300 kg︱
            plate thickness 10 mm
            - Working length 3080 mm
            - plate thickness (max.) 10 mm
            - stroke rate 20 /min
            - Back gauge adjustable . 1000 mm
            - total power consumption 22 kW
            - space requirements -left/right. 3800 mm
            - space requirements -front/back. 2050 mm
            - total height 2150 mm
            - total weight approx. 9300 kg
          Datasheet
          Request / Contact
          used Sheet metal working / shaeres / bending Plate Shear - Hydraulic ERMAK HVR CNC 3100-6


          • A + B Werkzeuge Maschinen Handels GmbH
          • Rottweg 17
          • 48683 Ahaus
          • Deutschland

          • (0049)-2561-9384-31
            (0049)-2561-9384-36
          • info@ab-maschinen.de
            www.ab-maschinen.de
          #1008-9322087 · Plate Shear - Hydraulic

          ERMAK - HVR CNC 3100-6 - - 2009 -

          Technical details
          sheet width 3100 mm︱plate thickness 6,0 mm︱distance between columns 3.100 mm︱down holder 14 Stück︱no. of strokes 16 - 24 Hub/min︱oil volume 150 ltr.︱cutting angle 0,5 - 1,5 °︱thickness at "Niro-steel" 4,0 mm︱column arm 350 mm︱engine output 11,0 kW︱weight of the machine ca. 8.300 kg︱range L-W-H 4,1 x 2,2 x 2,19 m︱
            sheet width 3100 mm
            plate thickness 6,0 mm
            distance between columns 3.100 mm
            down holder 14 Stück
            no. of strokes 16 - 24 Hub/min
            oil volume 150 ltr.
            cutting angle 0,5 - 1,5 °
            thickness at "Niro-steel" 4,0 mm
            column arm 350 mm
            engine output 11,0 kW
            weight of the machine ca. 8.300 kg
            range L-W-H 4,1 x 2,2 x 2,19 m
          Datasheet
          Request / Contact


          Hydraulic Plate Shear from LagerMaschinen.de
          Hydraulic plate shear from LagerMaschinen - a good choice

          When purchasing a hydraulic plate shear it’s important to gauge the precision of the machine. Luckily LagerMaschinen's experts are well-versed in machine calibration and precision gears. The hydraulic plate shear used for slicing large boards among many different materials absolutely exacts precision for its various tasks. By purchasing your used machine namely a hydraulic plate shear from LagerMaschinen you ensure 100% quality as well as safety. LagerMaschinen's custom installation service will provide your staff with all needed information. Get started today!

          LagerMaschinen.de's hydraulic plate shear

          By buying your used hydraulic plate shear from LagerMaschinen.de you ensure not only a wiser financial decision for your small business but you also increase your professional network. Using the LagerMaschinen platform you can interact with sellers of every machine available including the hydraulic plate shear thereby obtaining their advice or guidance most often in your geographical area. Your hydraulic plate shear from LagerMaschinen is therefore not only an investment in your business but possibly an investment in your professional network.

          Hydraulic plate shear - built to last

          The hydraulic plate shear especially when bought used needs special care. By interacting with both LagerMaschinen.de's sellers and with LagerMaschinen experts themselves you gain knowledge as well as a new business contact along the way. Additionally take advantage of LagerMaschinens.de's delivery and installation service including a demonstration of your new - but used - machine. By purchasing your hydraulic plate shear through LagerMaschinen you'll simply add to the list of clients who love this service. Join today and start searching for the perfect machine.
