milling machining centers - horizontal

CNC brand Heidenhain ︱CNC model 310 ︱Table length 1200 mm︱Table width 450 mm︱X 650 mm︱Y 480 mm︱Z 475 mm︱Spindle taper ISO 40 ︱Speed 4000 RPM︱

---

Center height: 160 mm 3-jaw chuck: 190 mm ø Spindle speed vertical: 1: 55-1,000 2: 1,001-4,000 RPM Equipped with 4th axis Kitagawa MAC

Control CNC ︱x-travel 600 mm︱y-travel 400 mm︱z-travel 380 mm︱table size 700 x 350 mm︱Axis 4 ︱tool adaptor SK40 ︱tool change unit 20-fach ︱weight of the machine ca. 3,8 t︱

---

x-travel 600 mm︱y-travel 400 mm︱z-travel 400 mm︱total power requirement 4 kW︱weight of the machine ca. 2 t︱dimensions of the machine ca. 2 x 2 x 2 m︱

---

Control Dialog 4 ︱Table length 1000 mm︱Table width 500 mm︱Spindle taper ISO 40 ︱

---

x-travel 1000 mm︱y-travel 400 mm︱z-travel 400 mm︱total power requirement 10 kW︱weight of the machine ca. 2,5 t︱dimensions of the machine ca. 2 x 3 x 2 m︱

---

x-travel 1250 mm︱y-travel 500 mm︱z-travel 500 mm︱table-size 1800x320 mm︱total power requirement kW︱weight of the machine ca. 5 t︱dimensions of the machine ca. m︱

---

horizontal for platt milling

CNC brand Siemens ︱CNC model 840 D Slimline ︱Table length 630 mm︱Table width 630 mm︱Number of pallets 2 ︱X 800 mm︱Y 900 mm︱Z 1050 mm︱Tool changer 63 ︱Max. workpiece diameter 11000 mm ø︱Maximum palletload 900 kg︱Machine weight 23000 kg︱Machine dimensions 2980 x 6487 x 3467 mm︱

---

x-travel 1400 mm︱y-travel 1050 mm︱z-travel 1200 mm︱Control Fanuc 31i-MA ︱spindle turning speed - stepless 6000 U/min︱spindle taper BT 50 ︱table surface area 800 x 800 x 2 mm︱table - indexing 1 Deg °︱total power requirement kW︱weight of the machine ca. 21 t︱dimensions of the machine ca. 7,1 x 4,8 x 3,3 m︱

---

- CNC control Fanuc 31i-MA - ATC for 60 tools (BT 50) - through spindle coolant 70 bar - Palettchanger 2-fold 800x 800mm

x-travel 730 mm︱y-travel 730 mm︱z-travel 880 mm︱Control M730 BM MAPPS IV︱Main spindle: ︱max. spindel speed 12.000 min/-1︱power capacity - milling spindle 15 / 11 kW︱max. Torque 102 Nm︱distance spindle center to table 80 - 800 mm︱distance spindle nose and table 70 - 950 mm︱pallet changer: .︱numbers of pallets 2 ︱size of pallet 500 x 500 mm︱max. workpiece weight 500 kg︱max. workpiecediameter 800 mm︱max. workpiece height 1.100 mm︱change time of pallets 9,5 sec︱Indexing-time 1,49 sec︱B-axis (table) 0,001 °︱Tool changer ︱

---

Milling Machining Center - Horizontal DMG MORI SEIKI NHX 5000 M730BM For accessoires please ask!

CNC brand Heidenhain ︱CNC model iTNC 530 ︱Table length 4500 mm︱Table width 1050 mm︱X 4100 mm︱Y 1250 mm︱Z 1350 mm︱Spindle taper ISO 50 ︱Tool changer 24 ︱Maximum speed 4000 RPM︱Maximum palletload 13000 kg︱Machine dimensions 12000 x 6500 x 4000 mm︱Machine weight 32000 kg︱

---

Chip conveyor Millinghead A+C Axis: 2,5° programmable Hydraulic tightening tools External cooling Oil cooler “Habor”

x-travel 560 mm︱y-travel 600 mm︱z-travel 600 mm︱pressure 9,7 t︱no. of strokes Hub/min︱sheet width mm︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 700 mm︱y-travel 800 mm︱z-travel 800 mm︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 750 mm︱y-travel 850 mm︱z-travel 600 mm︱Control CNC ︱weight of the machine ca. 27 t︱

---

x-travel 560 mm︱y-travel 560 mm︱z-travel 510 mm︱turning speeds 18000 U/min︱ ︱tool taper ISO 40 ︱Control ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 1600 mm︱y-travel 1250 mm︱z-travel 1600 mm︱Control Siemens ︱type 840D PL ︱B-axis (table) 360 ° ︱surface area 1250x1000 mm︱Workpiece dimensions 1100x1575 mm︱workpiece weight 5000 kg︱type of pallet-changer 2 fach︱tool taper SK 50 ︱tool change unit 80 fach︱tool length - max. 700 mm︱chip conveyor ︱measuring feelers - electric ︱spindle diameter 130 mm︱turning speeds 10-6000 U/min︱transmission ratio 2 ︱Spindle capacity 35 KW︱Cooling through the spindle bar︱

---

Tool length and tool breakage control

x-travel 650 mm︱y-travel 650 mm︱z-travel 650 mm︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 1600 mm︱y-travel 1250 mm︱z-travel 1000 mm︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 3400 mm︱y-travel 1350 mm︱z-travel 760 mm︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 1050 mm︱y-travel 800 mm︱z-travel 825 mm︱Control PC Fusion 640 M ︱size of pallet 800 x 630 mm︱table load 1,27 t︱table clamping surface: 24 x M16x2, Abstand 125 mm︱swivelling range 0,001° x 360000 Grad︱table height over floor 1250 mm︱Distance spindle nose - palett surface 200 - 1025 mm︱Distance spindle centre - table surface 50 - 850 mm︱feed range 1 - 40000 mm/min︱rapid travel x/y/z 40 m/min︱turning speed range 35 - 10000 U/min︱max. torque on the spindle 525 Nm︱power capacity - milling spindle 37 / 22 kW︱tool taper HSK 100 ︱chain magazin for tools 80 ︱diameter of tools max. 135 mm︱max. tool-dia with free toolbox 260 mm︱

---

x-travel 630 mm︱y-travel 630 mm︱z-travel 630 mm︱Control Siemens Sinumerik 840 D ︱size of pallet 400 x 500 mm︱workpiece height max. dia720 x 850 mm︱workpiece weight max. 500 kg︱tool taper HSK A63 ︱rotary table adjustment 360 x 1 °︱table turning speeds 25 U/min︱spindle turning speed range 16000 U/min︱spindle motor 30 kW︱Rapid Travel X / Y / Z-Achse 60 m/min︱total power requirement 60 kW︱weight of the machine ca. 6,5 t︱dimensions of the machine ca. 6,3 x 3,1 x m︱

---

- CNC Control Siemens SINUMERIK 840 D - Covering - Chip Conveyor - IKZ 50 bar - Tool Changer 40-fold (HSK A63) - Pallet Changer 6 machines available from 1999-2001

x-travel 630 mm︱y-travel 630 mm︱z-travel 630 mm︱Control SIEMENS SINUMERIK 840 D ︱total power requirement 60 kW︱weight of the machine ca. 8.500 kg︱dimensions of the machine ca. m︱

---

CNC brand Mazatrol ︱CNC model Fusion 640 M ︱Table length 630 mm︱Table width 630 mm︱Number of pallets 1 ︱X 1050 mm︱Y 800 mm︱Z 880 mm︱Spindle taper MAS BT 50 ︱Tool changer 80 ︱Minimum speed 35 RPM︱Maximum speed 7000 RPM︱Max. workpiece height 1000 mm︱Max. workpiece diameter 1050 mm ø︱Maximum palletload 1500 kg︱Machine dimensions 8050 x 4030 x 3530 mm︱Machine weight 19700 kg︱

---

x-travel 1640 mm︱y-travel 1300 mm︱z-travel 1220 mm︱control Mazatrol PC Fusion 640M ︱spindle turning speed - stepless 35 - 7000 U/min︱0 1000 x 1000 mm︱numbers of pallets 6 ︱spindle drive 30 / 22 kW︱spindle taper HSK 100 ︱tool piece magazine with 237 ︱feed 1 - 8000 mm/min︱rapid traverse 24 / 20 m/min︱workpiece dia. 1600 x 1440 mm︱workpiece weight max. 3000 kg︱b-axis 0-360 (x0,001) °︱distance spindle center to table 50 - 1350 mm︱total power requirement 72 kVA︱weight of the machine ca. 38 t︱

---

3/2016 new spindle and 8/2017 complete service and new ball screw in Z axis 4 axis CNC control Mazatrol PC Fusion 640M - automatic tool changer for 237 tools (HSK 100) - pallet changing device 6-fold - Mayfran chip conveyor - Mayfran HD coolant (70bar) - NC-Rotary Tabel with 4th Acis 360x0,001° - Mazak Monitoring System B (MP-10) - Optionspackage "Performance" - Air Filter - Measuring Probe Renishaw

x-travel 1.000 mm︱y-travel 750 mm︱z-travel 835 mm︱Control SINUMERIK 840D ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

Machining Center - Horizontal Brand: HECKERT / Type: CWK 630 / Year of construction: 2000 Commissioning: 03/09/2001 The machine can be inspected by appointment in the factory under power. Condition: Funcional. Operatinh hours (04.11.2020): 47.125 h TECHNICAL SPECIFICATIONS: Control: SIEMENS SINUMERIK 840D Number of controlled axes: 5 - X/Y/Z/C/B Travels: - X-axis: 1.000 mm - Y-axis: 750 mm - Z-axis: 835 mm - NC-Rotary table Speed: 18 rpm Measurement resolution: 0,001° (dregree) Partial table : 360 x 1° (degree) Pallet round storage with 4 storage spaces: - Pallet size: 1 x 630 x 800 mm, 3 x à 630 x 630 mm - 1 x Clamping point manually rotatable +/- 90° (degree) Tool magazine (Tower magazine): - 3 Towers - 165 Storage locations - Tool dimensions: max. length: 450/600 mm max. diameter: 110 mm Bridge-tool: 500 mm max. diameter with free adjacent pockets: 250 mm - Max. Tool diameter: 1.000 (Collision circle) mm Working spindle: - Speed range: 20 - 6.000 rpm - Feed: Stepless 1 - 2.400 mm/min - Torque: 1.210 Nm (25% ED) - Main engine spindle: 28 kW (100% ED), 50 kW (25% ED) - Tool holder: HSK 100 A EQUIPMENT: - Pallet round storage - Chip conveyor - Beld filter - Coolant unit with temperature stabilization, capacity: 900 l - Splash shower , 200 l/min - Measurement probe Renishaw - Breakage monitoring - Tool changer: Tower magazine - Coolant through the spindle 30, 40, 50 bar over M-command switchable - Temperature compensation - Emission extraction - Documentation - CE marking There is no guarantee for correctness and completeness of the technical details and accessories.
