Universal Milling Machine

x-travel 620 mm︱y-travel 520 mm︱z-travel 460 mm︱Control Heidenhain TNC 640 HSCI ︱surface area 650 mm︱table rotation 360 °︱tablemovement on both sides -50 / + 110 °︱table load 300 kg︱T-slots 5 x 18 H7 x 100 ︱distance spindle nose and table 180 - 640 mm︱c-axis 360 °︱B-axis (table) -50 / + 110 °︱turning speeds 20-12.000 (15.+18+24.000) U/min︱spindle motor 33 / 180 (17/108) kW / Nm︱rapid traverse x / y + z - axis 48 m/min︱b-axis 25 UpM︱c-axis 25 UpM︱numbers of tools in magazin 48 (60/120) ︱spindle taper SK 40 / BT 40 / HSK 63A ︱total connect load 35 kW︱

---

New 5-axis machining center WEMAS VZG 65 - 5A Generation II for simultaneous milling and full 5-side machining, Heidenhain glass scales in x, y, z, directly Encoder Heidenhain in B, C. Main spindle AC - direct drive motor, digital axle drives, extensive standard equipment such as conveyor belt chip conveyor,elec. handwheel, control cabinet cooling, spindle cooling, z-axis temperature compensation, full protection cabin (without cab roof),coolant unit with cabin flushing / external coolant / IKZ 30 bar / hand rinse with additional gun, four guideways in the Y axis, data interfaces. As an alternative to the Heidenhain control, Siemens 840 D SL can also be offered. Many optional accessories available as different speed ratings of the main spindle, tool changer in various number of toolpositions, various internal cooling systems with multiple pressure outputs and filters, laser measuring system, blown air, oil mist suction, hydraulic clamp, instruction and training and much more.

x-travel 500 mm︱y-travel 400 mm︱z-travel 300 mm︱control Sinumerik 828D Siemens︱Main spindle: ︱turning speed range - main spindle max. 16.000 min/-1︱power capacity - main spindel 22,8 / 12 kW︱max. Torque 116 Nm︱tool taper BT 30 DIN 69871︱work table: ︱table surface area 650 x 400 mm︱max. table load 250 kg︱T-slots 3x 14 x 125 mm︱distance spindle /table 150 - 450 mm︱Tool-Presetter: ︱number of toolpositions 21 pos.︱tool taper BT 30 ︱max. tool diameter 80 mm︱max. tool length 80 mm︱max. tool weight 3,0 kg︱

---

CNC-MachiningCenter Universal OPTIMUM - OPTImill F 120 X - NEW MACHINE / SHOW-ROOM-MACHINE - alternative configuration available, optional and on request !

x-axis 3000 mm︱y-travel 1500 mm︱z-travel 1400 mm︱spindle turning speed range 12000 U/min︱spindle taper HSK 100︱Spindle capacity 50 KW︱control Heidenhain ITNC 530 ︱surface area 1250x1600 mm︱table load capacity - central/maximum 8000 kg︱A-axis +-185 °︱b-axis +-185 °︱c-axis 360 °︱Tool changer 60 ︱total power requirement 80 KVA︱weight of the machine ca. 33 t︱dimensions of the machine ca. 7,8x7,5x4 m︱

---

x-travel 935 mm︱y-travel 850 mm︱z-travel 650 mm︱Control iTNC 530 HSCI ︱rotary table diameter 850x750 mm︱table surface area 1.000x750 mm︱table weight 1.000 Kg︱spindle turning speed - stepless 18.000 U/min︱taper ISO SK 40 ︱tool change unit 60 pos.︱Machine on 14.500 h︱Spindle hours 4.000 h︱total power requirement 50 kW︱weight of the machine ca. 13,7 t︱dimensions of the machine ca. 4,7 (4,1) x 3 x H 3,2 m︱

---

-5-axis simultaneous machining center -NC swivel rotary table, A-axis +-120°, C-axis 360°, -Probe HEIDENHAIN TS 649, -BLUM lasers, -3D quickset software, -MPC, -ATC, -IKZ 40 bar, 600 liters, -chip conveyor, -flush gun, -coolant ring nozzle, -internal blown air, -el. handwheel, -red. lens, -mechanical suction,

x-travel 1020 mm︱y-travel 610 mm︱z-travel 610 mm︱c-axis 360 /610mm 0︱b-axis +30 -120 °︱control Heidenhain 530 ︱weight of the machine ca. 9000 t︱

---

x-travel 885 mm︱y-travel 800 mm︱z-travel 520 mm︱Control iTNC 530 ︱turning speeds 12.000 U/min︱tool adaptor SK40 ︱table-size 600x500 mm︱table weight 300 Kg︱tool change unit 48 pos.︱Machine on 20.000 h︱Spindle hours 10.000 h︱total power requirement 25 kW︱weight of the machine ca. 12 t︱dimensions of the machine ca. 4,15 x 3,8 x 3,28 m︱

---

-5-axis simultaneous machining center, -NC rotary swivel table, C-axis 360°, B-axis +30-120°, -chip conveyor, -IKZ 20bar, 400l, -flush gun, -direct measuring system, -Blown air outside, -temperature compensation, -el. handwheel

x-travel 600 mm︱y-travel 855 mm︱z-travel 750 mm︱table surface area 400 x 400 mm︱clearance diameter 720 mm︱table rotation speed 50 U/min︱pivoting angle -185 / +45 Grad︱workpiece weight 340 kg︱tool taper HSK-A 63 ︱spindle turning speed - stepless 12000 U/min︱spindle motor 40 kW︱tool diameter 70 mm︱tool length - max. 365 mm︱weight of tools max. 8 kg︱rapid travel range 70/45/90 m/min︱control Heidenhain iTMC 530 ︱total power requirement 54 kVA︱weight of the machine ca. 15 t︱dimensions of the machine ca. 6,1 x 2,47 x 3,17 m︱

---

The 5-axis universal machining center G350 offers nearly unlimited possibilities in the milling of workpieces of various materials. materials. equipped with: - CNC control Heidenhain iTNC 530 - 2-fold Pallet Changer - NC swivel rotary table (A-/B-axis) - tool changer 40 places (HSK A63) - IKZ / coolant system 3-22,5bar - chip conveyor

x-travel 550 mm︱y-travel 410 mm︱z-travel 450 mm︱b-axis +110/-110 °︱spindle turning speed range -15000 U/min︱spindle taper BT Big Plus 40 ︱tool change unit 40x ︱size of pallet 2x D-250 mm︱weight of the machine ca. 8.6 t︱

---

5 axes machining center FANUC G-Tech 30i Coolant through spindle 3D measuring probe Tool measuring device Misc pallets Misc tool holders More details on www.marcels-maschinen.ch

x-travel 400 mm︱y-travel 400 mm︱z-travel 400 mm︱Control Siemens 840D ︱Number of boring spindles 2 St.︱spindle distance 400 mm︱spindle turning speed range 50 - 10000 U/min︱spindle drive 18 kW︱Number of working hours ca. 63015 h︱spindle hours ca. 32870 h︱ ︱no. of tables 1 ︱no. of clamping positions 4 ︱max. workpiece weight 450 kg︱tool magazin: ︱number of tool places 60 (120) Pos.︱tool taper HSK A63 ︱max. tool diameter 70 mm︱max. tool length 300 mm︱max. tool weight 10 kg︱

---

In our opinion, the machine is in very good condition and can be inspected under power by appointment. - There are 2 identical machines available ***Accessories, tools and clamping devices shown are only part of the scope of delivery if this is noted in the additional information.***

x-travel 600 mm︱y-travel 700 mm︱z-travel 600 mm︱spindle turning speed range 24.000 U/min︱control Heidenhein iTNC 530 ︱tool taper HSK 63 ︱Internal cooling system 40 bar︱tool magazin: 120 pos.︱table-size 630 x 500 mm︱Machine on 71581 h︱Spindle hours 31755 h︱table weight 500 Kg︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 600 mm︱y-travel 855 mm︱z-travel 750 mm︱table surface area 570 mm︱clearance diameter 720 mm︱pivoting angle -185 / +45 Grad︱workpiece weight 400 kg︱table rotation speed 50 U/min︱tool taper HSK-A 63 ︱spindle turning speed - stepless 12000 U/min︱spindle motor 40 kW︱tool diameter 70 mm︱tool length - max. 365 mm︱weight of tools max. 8 kg︱rapid travel range 70/45/90 m/min︱control Heidenhain iTMC 530 ︱total power requirement 47 kVA︱weight of the machine ca. 13 t︱dimensions of the machine ca. 6,1 x 2,47 x 3,17 m︱

---

The 5-axis universal machining center G350 offers nearly unlimited possibilities in the milling of workpieces of various materials. materials. equipped with: - CNC control Heidenhain iTNC 530 - NC swivel rotary table (A-/B-axis) - tool changer 40 places (HSK A63) - IKZ / coolant system 3-22,5bar - chip conveyor 2 identic machines available

x-travel 600 mm︱y-travel 500 mm︱z-travel 500 mm︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

CNC control Sinumerik 840D NC-swivel rotary table (A-axis and C-axis) electronical handwheel automatic tool changer for 40 tools chip conveyor no coolant device Technische Daten / technical details: X-Weg / X-travel 600 mm Y-Weg / Y-travel 500 mm Z-Weg / Z-travel 500 mm A-Achse Schwenktisch / A-axis swivel table +-120 ° C-Achse Rundtisch / C-axis rotary table 360 ° Spindelaufnahme / spindle taper HSK63 Drehzahlbereich Spindel / spindle speed 50-15000 Upm /rpm Rundtischdurchmesser / rotary table diameter 600 mm Antriebsleistung Spindel 40%/100%ED / drive capacity spindle 40%/100%ED 35/22,5 kW Gewicht der Maschine ca. / weight 9500 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Control Fanuc ︱x-travel 850 mm︱y-travel 520 mm︱z-travel 510 mm︱changer 24 Plätze︱tool adaptor SK40 ︱ max. 10.000 U/Min︱chip conveyor ︱weight of the machine ca. 12 t︱

---

x-travel 2.000 mm︱y-travel 1.100 mm︱z-travel 700 mm︱Control Sinumerik 840 D PL Siemens︱Main spindle: ︱turning speed range - main spindle 28.000 min/-1︱power capacity - main spindel 14 kW︱tool taper HSK 50 E ︱swivellable A /C : +/- 120 °︱speed 180 °/sec.︱indexing 0,001 °︱work table: ︱table surface area 3.000 x 1.850 mm︱T-slots H7 ︱Tool-Presetter: ︱number of toolpositions 14 pos.︱tool taper HSK 50 E ︱feeds: ︱rapid traverse ( X / Y / Z ) 55 m/min︱total power requirement - kW︱

---

CNC-Machiningcenter Universal HANDTMANN / BAVIUS - PBZ DL 5 - 5-Axis - only ca. 500h operating hours, only ca. 259h spindle hours - plastic and aluminum machining only - internal and external minimum quantity lubrication

x-travel 600 mm︱y-travel 450 mm︱z-travel 450 mm︱Control ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

CNC control Heidenhain iTNC530 NC swivel-rotary table (B-axis and C-axis) 170-fold automatic tool changer electronical hand wheel measuring feeler coolant through spindle device (IKZ) chip conveyor coolant device Technische Daten / technical details: Verfahrweg X / X-Travel 600 mm Verfahrweg Y / Y-Travel 450 mm Verfahrweg Z / Z-Travel 450 mm B-Achse Schwenktisch / B-axis swivel table -115 / +30 ° C-Achse Rundtisch / C-axis rotary table 360 ° Tischgröße / table size System 3R mm Werkzeugschaft / spindle taper HSK A63 Drehzahlbereich / spindle speed 100-20000 UpM /rpm Werkzeugwechsler / tool changer 170 fach /fold Antriebsleistung Spindel 40%/100%ED / drive capacity spindle 40%/100%ED 30/23 kW Gewicht der Maschine ca. / weight ca. 9000 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

x-travel 700 mm︱y-travel 715 mm︱z-travel 850 mm︱table-size 500 x 500 mm︱tool taper ISO 40 ︱Control Fanuc 16i-MB ︱total power requirement kW︱weight of the machine ca. 21 t︱dimensions of the machine ca. m︱

---

x-travel 1300 mm︱y-travel 600 mm︱z-travel 800 mm︱table-size 1515x635 mm︱round table 630 ︱spindle taper HSK63 ︱spindle turning speed range 15000 U/min︱tool change unit 36x ︱weight of the machine ca. 8.5 t︱

---

HEIDENHAIN iTNC530 Swivel axis milling head +/- 105° Integrated NC rotary table D-630mm 3D tracer RENISHAW www.marcels-maschinen.ch

x-travel 4000 mm︱y-travel 1500 mm︱z-travel 3500 mm︱control Siemens 840 D ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

Machine was producing parts of airplane Motors for Rolls Royce. Machine very little used and as new. Machine with 2 pallet tables, diamter 1500 mm 2 x ATC 40 tool changer Automatic milling head 1ºx1º indexing, 37 kW Max. spindle speed 5000 rpm coolant equipment with paper band filter coolant through spindle min./max. 20-60 bar

travel -x axis 730 mm︱travel -y axis 560 mm︱travel -z axis 560 mm︱Control Heidenhain - iTNC 530 ︱spindle taper SK 40 ︱spindle turning speed range 12000 U/min︱surface area 600 x 1.000 mm︱rotary table dia. 600 mm︱spindle motor 15 / 10 kW︱dimensions of the machine ca. 3,2 x 2,11 x 2,62 m︱weight of the machine ca. 6,6 t︱

---

5-axis machining centre equipped with: - CNC control Heidenhain iTNC 530 - NC swivel head B axis (-120/+30°) - NC rotary table C-axis - Tool magazine 24-fold (SK 40) - IKZ 40bar - Operating mode 4 - Tool measurement in the working area - Chip conveyor

x-travel 760 mm︱y-travel 510 mm︱z-travel 610 mm︱Control Ultimax ︱total power requirement kW︱weight of the machine ca. 4700 t︱dimensions of the machine ca. 3670x4000x2700 m︱

---

x-travel 3800 mm︱y-travel 2000 mm︱z-travel 670 mm︱Control Siemens ︱type 840 D sl︱surface area 3000x1800 mm︱milling spindle 120 KW︱turning speeds 30.000 U/min︱tool holder HSK 63 ︱Tool changer 124 Pos︱c-axis ︱angular milling head ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 1.000 (1.245) mm︱y-travel 630 mm︱z-travel 550 mm︱Control HEIDENHAIN iTNC 530 ︱total power requirement 17 kVA︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

Milling Machining Centre - Universal / Brand: HERMLE / Type: U 1000 A / Year of construction: 2003 (4.5-axis machine: 4 axes + swivel head, approach axis) The machine can be inspected by appointment under working condition. Condition: Ready for operation, fully functional. Operating hours (as of 07 September 2021): - Control on: 37.628 h - Machine on: 36.859 h - Program run: 12.019 h - Spindle on: 9.339 h - Axes in motion: 10.303 h TECHNICAL DATA: - Control: HEIDENHAIN iTNC 530 Travels: - X-axis: 1.000 (1.245) mm (depending on the milling head position) - Y-axis: 630 mm - Z-axis: 550 mm - C-axis (NC-Rotary table): 360° - Universal milling head with quill: 90° Milling head position: - Vertical: X-axis = 1.000 mm - 0 - 39°: X-axis = 1.000 mm - 40 - 90°: X-axis = 1.245 mm Spindle: - Speed range: 20 - 7.000 rpm - Tool holder: SK 40 - Drive power approx.: 7,5 kW Feeds and rapid traverse: - Feed range X/Y-axis: 1 - 20.000 mm/min - Rapid traverse X/Y approx.: 20 m/min - Feed range Z-axis: 1 - 15.000 mm/min - Rapid traverse approx.: 10 m/min NC-Rotary table: - Clamping surface Ø: 800 mm - Table load max.: 700 kg - Weight of the table: 880 kg - Rotation range of the NC-Rotary table (C-axis): 360° - Table top: Number / Width of the T-Slots (arranged in a star shape): 8/14 H7 - Centering hole: Ø 32 H6/15 deep - Measuring system accuracy: Resolution: +/- 8" - Partial accuracy: +/- 8" - C-axis speed: max. Rotation speed (at 10%): 11 rpm Connection values: - Operating voltage: 400 V/50 Hz - Control voltage: 24 V - Total nominal current: 24 A - Total power requirement: 17 kVA - Total weight approx.: 6,5 tons EQUIPMENT: - Tool magazine positions: 16 - Full protection cabin - Coolant device - Swiveling control panel - Electronic handwheel - Documentation - CE marking NO chip conveyor ! There is no guarantee for correctness and completeness of the technical details and accessories.

x-travel 6000 mm︱y-travel 1000 mm︱z-travel 1200 mm︱table-size 6400x1000 mm︱tool change unit 80x ︱spindle taper HSK A100 ︱spindle turning speed range 45-9000 U/min︱total power requirement kW︱weight of the machine ca. 48 t︱dimensions of the machine ca. 12x4.3x4.5 m︱

---

SIEMENS 840D 4th axis B-Axis +/-90° Spindle coolant through spindle Tool measuring device www.marcels-maschinen.ch

x-travel 880 mm︱y-travel 630 mm︱z-travel 630 mm︱table surface area 1250 x 700 mm︱NC-rotary table integriert, 700 mmø︱spindle taper SK 40 ︱spindle taper DIN 69871 ︱spindle turning speed - stepless 20 - 12.000 U/min︱control HEIDENHAIN ︱control TNC 430 ︱feeds x/y/z -stepless 20 - 15.000 mm/min︱rapid traverse 30 m/min︱ATC 32 (2 x 16) Pos︱tool diameter 80 / 130 mm︱workpiece length 315 mm︱weight of tools max. 8 kg︱NC-rotary table - speed - max. 15 U/min︱table load 600 / 500 kg︱total power requirement 60 kW︱weight of the machine ca. 9,6 t︱

---

= 5-axis machining center, table clamping surface 1250 x 700 mm with integrated NC-rotary table (=4th axis), movement of milling head via control (=5th axis) Accessories: electron. handwheel, chip conveyor (snailconveyor), coolant
